This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 82.44 inches by 40.87 inches and an array layout of 3 wide by 5 high.
This mount fits on 1 – 10in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
1211ArrowheadDriveSolar-RevF
$5,974.99
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 82.44 inches by 40.87 inches and an array layout of 3 wide by 5 high.
This mount fits on 1 – 10in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
Weight | 1208.8700000000001 lbs |
---|---|
Dimensions | 90 × 24 × 24 in |
SKU CODE | 1P-0-10TOP-XD-72-L-5HX3W-B587 |
DUTY SIZE | XD |
POLE SIZE | 10IN, PIPE, SCH, 40 |
PRODUCT TYPE | BEAM |
NUMBER OF POLES | 1.00 |
POLE SPACING | 0.00 |
POLE HEIGHT | 11.20 |
WING SPAN | 72.00 |
MAX FOUNDATION DEPTH | 7.50 |
TILT ANGLE | 46.00 |
CANTILEVER | 234.00 |
GROUND CLEARANCE | 5.00 |
NO POLES | 1.00 |
MODULE AREA | 359.57 |
ARRAY WIDTH | 20.86 |
ARRAY HEIGHT | 17.24 |
RAIL LENGTH | 206.85 |
MODULE LENGTH | 82.44 |
PASSED OVERHANG CHECK | TRUE |
MODULE WIDTH GAP | 0.50 |
MODULE LENGTH GAP | 1.00 |
TOTAL FRAME LENGTH | 19.50 |
GROUND TO TOP | 17.32 |
PROJECTED PANEL HEIGHT | 12.25 |
WIND SPEED OVERRIDE | 140.00 |
SNOW LOAD OVERRIDE | 50.00 |
DIRECT SNOW LOAD | FALSE |
PROJECT ID | 1211ARROWHEADDRIVESOLAR-REVF |
SITE ADDRESS | 1211, ARROWHEAD, DR, JEFFERSON, CO, 80456, USA |
MODULE WIDTH | 40.87 |
NUMBER ROWS | 5.00 |
NUMBER COLUMNS | 3.00 |
RISK CATEGORY | I |
EXPOSURE CATEGORY | C |
FRAME DUTY OVERRIDE | XD |
POLE OVERRIDE | 10, 40 |
SOIL TYPE | SAND |
FOUNDATION TYPE | SQUARE |
FOUNDATION SIZE | 48.00 |
CHECK RAILS | TRUE |
TOTAL PRICE | 5974.99 |
TOTAL WEIGHT | 1208.87 |
TOTAL PALLETS | 1.00 |
https://skycivquotes.s3.amazonaws.com/396a9cd3-636a-45e0-8924-bcb2f4eb618d.pdf |
|
ID | 605.00 |
3D Solar link |
