This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 74 inches by 41.1 inches and an array layout of 2 wide by 2 high.
This mount fits on 1 – 4in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
ArcataProject-RevA
$3,061.28
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 74 inches by 41.1 inches and an array layout of 2 wide by 2 high.
This mount fits on 1 – 4in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
Additional information
https://solver.skyciv.com/temp/mergedpdf_bjffzq5eo68ggk40.php |
|
| SKU CODE | 1P-0-6TOP-SD-24-L-2Hx2W |
| DUTY SIZE | SD |
| POLE SIZE | 4in, Pipe, Sch, 40 |
| PRODUCT TYPE | Cyber |
| NUMBER OF_POLES | 1 |
| POLE SPACING | 15 |
| POLE HEIGHT | 4.73 |
| WING SPAN | 24 |
| FOUNDATION DEPTHS | [object, Object] |
| TILT ANGLE | 30 |
| CANTILEVER | 138 |
| GROUND CLEARANCE | 3 |
| NO POLES | 1 |
| MODULE AREA | 86.66666666666667 |
| ARRAY WIDTH | 12.5 |
| ARRAY HEIGHT | 6.933333333333334 |
| RAIL LENGTH | 83.2 |
| MODULE LENGTH | 74 |
| PASSED OVERHANG_CHECK | true |
| MODULE WIDTH_GAP | 0.5 |
| MODULE LENGTH_GAP | 1 |
| TOTAL FRAME_LENGTH | 11.5 |
| GROUND TO_TOP | 6.445833333333334 |
| PROJECTED PANEL_HEIGHT | 3.4250000000000003 |
| WIND SPEED_OVERRIDE | null |
| SNOW LOAD_OVERRIDE | null |
| DIRECT SNOW_LOAD | false |
| PROJECT ID | ArcataProject-RevA |
| SITE ADDRESS | 115, Center, St, Arcata, CA, 95521, USA |
| MODULE WIDTH | 41.1 |
| NUMBER ROWS | 2 |
| NUMBER COLUMNS | 2 |
| MAIN PIPE_SECTION | 2_10GA |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | B |
| SOIL TYPE | sand |
| FOUNDATION TYPE | Round |
| FOUNDATION SIZE | 36 |
| CHECK RAILS | true |
| TOTAL PRICE | 3061.2799999999997 |
| TOTAL WEIGHT | 529.92 |
| TOTAL PALLETS | 1 |
| ID | 177 |
