This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 45 inches by 89 inches and an array layout of 11 wide by 3 high.
This mount fits on 2 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 19.75 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Boat Pad – Portrait – 20ft – V1Jb
$11,897.63
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 45 inches by 89 inches and an array layout of 11 wide by 3 high.
This mount fits on 2 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 19.75 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
| Weight | 2170.72 lbs |
|---|---|
| Dimensions | 90 × 24 × 24 in |
| SKU CODE | 2P-19.75-6TOP-XD-84-L-3HX11W-03IA |
| DUTY SIZE | XD |
| POLE SIZE | 6IN, PIPE, SCH, 40 |
| PRODUCT TYPE | BEAM |
| NUMBER OF POLES | 2.00 |
| POLE SPACING | 19.75 |
| POLE HEIGHT | 13.98 |
| WING SPAN | 84.00 |
| MAX FOUNDATION DEPTH | 6.25 |
| TILT ANGLE | 5.00 |
| CANTILEVER | 495.00 |
| GROUND CLEARANCE | 13.00 |
| NO POLES | 2.00 |
| MODULE AREA | 943.48 |
| ARRAY WIDTH | 42.17 |
| ARRAY HEIGHT | 22.38 |
| RAIL LENGTH | 268.50 |
| MODULE LENGTH | 45.00 |
| PASSED OVERHANG CHECK | TRUE |
| MODULE WIDTH GAP | 0.50 |
| MODULE LENGTH GAP | 1.00 |
| TOTAL FRAME LENGTH | 41.25 |
| GROUND TO TOP | 14.95 |
| PROJECTED PANEL HEIGHT | 1.95 |
| WIND SPEED OVERRIDE | 156.00 |
| SNOW LOAD OVERRIDE | NULL |
| DIRECT SNOW LOAD | FALSE |
| ADD ANGLE BRACE | FALSE |
| DESIGNER NAME | |
| DESIGNER EMAIL | |
| DESIGNER PHONE | |
| PROJECT ID | BOAT, PAD, -, PORTRAIT, -, 20FT, -, V1JB |
| SITE ADDRESS | MIAMI, FL, USA |
| MODULE WIDTH | 89.00 |
| NUMBER ROWS | 3.00 |
| NUMBER COLUMNS | 11.00 |
| POLE SPACING OVERRIDE | 19.75 |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | B |
| FRAME DUTY OVERRIDE | AUTO |
| POLE OVERRIDE | AUTO |
| SOIL TYPE | SAND |
| CUSTOMER FOUNDATION OVERRIDE | 48, SQUARE |
| FOUNDATION TYPE | SQUARE |
| FOUNDATION SIZE | 48.00 |
| CHECK RAILS | TRUE |
| TOTAL PRICE | 11897.63 |
| TOTAL WEIGHT | 2170.72 |
| TOTAL PALLETS | 2.00 |
