This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 74.8 inches by 40.9 inches and an array layout of 6 wide by 5 high.
This mount fits on 2 – 10in Pipe Sch 40 inch steel pole(s) with a spacing of 22.5 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
CCC-RevB
$11,958.65
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 74.8 inches by 40.9 inches and an array layout of 6 wide by 5 high.
This mount fits on 2 – 10in Pipe Sch 40 inch steel pole(s) with a spacing of 22.5 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
Additional information
| Weight | 3586 lbs |
|---|---|
| Dimensions | 90 × 24 × 24 in |
| SKU CODE | 2P-22.5-10TOP-XD-45-L-5HX6W |
| DUTY SIZE | XD |
| POLE SIZE | 10IN, PIPE, SCH, 40 |
| PRODUCT TYPE | BEAM |
| NUMBER OF_POLES | 2 |
| POLE SPACING | 15 |
| POLE HEIGHT | 19.31 |
| WING SPAN | 45 |
| FOUNDATION DEPTHS | [OBJECT, OBJECT] |
| TILT ANGLE | 30 |
| CANTILEVER | 450 |
| GROUND CLEARANCE | 15 |
| NO POLES | 2 |
| MODULE AREA | 653.775 |
| ARRAY WIDTH | 37.9 |
| ARRAY HEIGHT | 17.25 |
| RAIL LENGTH | 207 |
| MODULE LENGTH | 74.8 |
| PASSED OVERHANG_CHECK | TRUE |
| MODULE WIDTH_GAP | 0.5 |
| MODULE LENGTH_GAP | 1 |
| TOTAL FRAME_LENGTH | 37.5 |
| GROUND TO_TOP | 23.572916666666664 |
| PROJECTED PANEL_HEIGHT | 8.520833333333329 |
| WIND SPEED_OVERRIDE | NULL |
| SNOW LOAD_OVERRIDE | NULL |
| DIRECT SNOW_LOAD | FALSE |
| PROJECT ID | CCC-REVB |
| SITE ADDRESS | 714, S, 8TH, AVE, BOZEMAN, MT, 59715, USA |
| MODULE WIDTH | 40.9 |
| NUMBER ROWS | 5 |
| NUMBER COLUMNS | 6 |
| MAIN PIPE_SECTION | 2, 12GA |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | B |
| POLE OVERRIDE | AUTO |
| SOIL TYPE | SAND |
| FOUNDATION TYPE | SQUARE |
| FOUNDATION SIZE | 48 |
| CHECK RAILS | FALSE |
| TOTAL PRICE | 11958.65 |
| TOTAL WEIGHT | 2415.3399999999997 |
| TOTAL PALLETS | 2 |
