This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 81.1 inches by 39.3 inches and an array layout of 14 wide by 5 high.
This mount fits on 5 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
HeraeusSolarPanelCarportsSFSCA-JB-RevA
$23,319.67
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 81.1 inches by 39.3 inches and an array layout of 14 wide by 5 high.
This mount fits on 5 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
Additional information
https://solver.skyciv.com/temp/mergedpdf_ifkd24slusoo4wc4.php |
|
| SKU CODE | 5P-19.75-6TOP-SD-45-L-5Hx14W |
| DUTY SIZE | SD |
| POLE SIZE | 6in, Pipe, Sch, 40 |
| PRODUCT TYPE | Beam |
| NUMBER OF_POLES | 5 |
| POLE SPACING | 15 |
| POLE HEIGHT | 9.01 |
| WING SPAN | 45 |
| FOUNDATION DEPTHS | [object, Object] |
| TILT ANGLE | 7 |
| CANTILEVER | 1128 |
| GROUND CLEARANCE | 8 |
| NO POLES | 5 |
| MODULE AREA | 1588.406944444444 |
| ARRAY WIDTH | 95.78333333333332 |
| ARRAY HEIGHT | 16.583333333333332 |
| RAIL LENGTH | 199 |
| MODULE LENGTH | 81.1 |
| PASSED OVERHANG_CHECK | true |
| MODULE WIDTH_GAP | 0.5 |
| MODULE LENGTH_GAP | 1 |
| TOTAL FRAME_LENGTH | 94 |
| GROUND TO_TOP | 10.008305221530659 |
| PROJECTED PANEL_HEIGHT | 1.995610498259289 |
| WIND SPEED_OVERRIDE | null |
| SNOW LOAD_OVERRIDE | null |
| DIRECT SNOW_LOAD | false |
| PROJECT ID | HeraeusSolarPanelCarportsSFSCA-JB-RevA |
| SITE ADDRESS | 15524, Carmenita, Rd, Santa, Fe, Springs, CA, 90670, USA |
| MODULE WIDTH | 39.3 |
| NUMBER ROWS | 5 |
| NUMBER COLUMNS | 14 |
| MAIN PIPE_SECTION | 2_12GA |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | C |
| SOIL TYPE | sand |
| FOUNDATION TYPE | Square |
| FOUNDATION SIZE | 48 |
| CHECK RAILS | false |
| TOTAL PRICE | 23319.67 |
| TOTAL WEIGHT | 4618.16 |
| TOTAL PALLETS | 5 |
| ID | 195 |
