This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 65 inches by 40 inches and an array layout of 3 wide by 5 high.
This mount fits on 1 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
Jordan_Homestead_Cow_Shade
$4,412.39
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 65 inches by 40 inches and an array layout of 3 wide by 5 high.
This mount fits on 1 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
Additional information
https://solver.skyciv.com/temp/mergedpdf_rqd3a5f16aoggskw.php |
|
| SKU CODE | 1P-0-6TOP-SD-45-L-5Hx3W |
| DUTY SIZE | SD |
| POLE SIZE | 6in, Pipe, Sch, 40 |
| PRODUCT TYPE | Beam |
| NUMBER OF_POLES | 1 |
| POLE SPACING | 15 |
| POLE HEIGHT | 11.07 |
| WING SPAN | 45 |
| FOUNDATION DEPTHS | [object, Object] |
| TILT ANGLE | 46 |
| CANTILEVER | 180 |
| GROUND CLEARANCE | 5 |
| NO POLES | 1 |
| MODULE AREA | 278.4375 |
| ARRAY WIDTH | 16.5 |
| ARRAY HEIGHT | 16.875 |
| RAIL LENGTH | 202.5 |
| MODULE LENGTH | 65 |
| PASSED OVERHANG_CHECK | true |
| MODULE WIDTH_GAP | 0.5 |
| MODULE LENGTH_GAP | 1 |
| TOTAL FRAME_LENGTH | 15 |
| GROUND TO_TOP | 17.063927901512795 |
| PROJECTED PANEL_HEIGHT | 11.988996672310854 |
| WIND SPEED_OVERRIDE | null |
| SNOW LOAD_OVERRIDE | null |
| DIRECT SNOW_LOAD | false |
| PROJECT ID | Jordan_Homestead_Cow_Shade |
| SITE ADDRESS | 35210, Canyon, Mill, Rd, Ronan, MT, 59864, USA |
| MODULE WIDTH | 40 |
| NUMBER ROWS | 5 |
| NUMBER COLUMNS | 3 |
| MAIN PIPE_SECTION | 2_12GA |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | B |
| SOIL TYPE | sand |
| FOUNDATION TYPE | Square |
| FOUNDATION SIZE | 48 |
| CHECK RAILS | false |
| TOTAL PRICE | 4412.389999999999 |
| TOTAL WEIGHT | 856.3199999999999 |
| TOTAL PALLETS | 1 |
| ID | 119 |
