Polasek MTSOLAR_II1I61H021L3

$11,765.46

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 74 inches by 41.1 inches and an array layout of 8 wide by 4 high.
This mount fits on 3 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 17 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Add a PE Stamped Drawing for this mount

For permitting, get a Professional Engineer's stamp on your construction drawing.

SKU: 3P-17-6TOP-SD-45-L-4Hx8W-EF4L Category:

Description

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 74 inches by 41.1 inches and an array layout of 8 wide by 4 high.
This mount fits on 3 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 17 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Additional information

Weight 2073.76 lbs
Dimensions 90 × 24 × 24 in
SKU CODE

3P-17-6TOP-SD-45-L-4HX8W-EF4L

DUTY SIZE

SD

POLE SIZE

6IN, PIPE, SCH, 40

PRODUCT TYPE

BEAM

NUMBER OF POLES

3.00

POLE SPACING

17.00

POLE HEIGHT

10.31

WING SPAN

45.00

MAX FOUNDATION DEPTH

7.50

TILT ANGLE

50.00

CANTILEVER

588.00

GROUND CLEARANCE

5.00

NO POLES

3.00

MODULE AREA

693.33

ARRAY WIDTH

50.00

ARRAY HEIGHT

13.87

RAIL LENGTH

166.40

MODULE LENGTH

74.00

PASSED OVERHANG CHECK

TRUE

MODULE WIDTH GAP

0.50

MODULE LENGTH GAP

1.00

TOTAL FRAME LENGTH

49.00

GROUND TO TOP

15.56

PROJECTED PANEL HEIGHT

10.49

PROJECT ID

POLASEK, MTSOLAR, II1I61H021L3

SITE ADDRESS

1053, CO, RD, 8, FRASER, CO, 80442, USA

MODULE WIDTH

41.10

NUMBER ROWS

4.00

NUMBER COLUMNS

8.00

RISK CATEGORY

I

EXPOSURE CATEGORY

B

FRAME DUTY OVERRIDE

AUTO

POLE OVERRIDE

AUTO

SOIL TYPE

SAND

CUSTOMER FOUNDATION OVERRIDE

36, ROUND

FOUNDATION TYPE

ROUND

FOUNDATION SIZE

36.00

CHECK RAILS

FALSE

WIND SPEED OVERRIDE

115.00

SNOW LOAD OVERRIDE

90.00

DIRECT SNOW LOAD

FALSE

ADD ANGLE BRACE

FALSE

TOTAL PRICE

11765.46

TOTAL WEIGHT

2073.76

TOTAL PALLETS

3.00
