This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 81.4 inches by 41.2 inches and an array layout of 4 wide by 3 high.
This mount fits on 2 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
PR04310 Larry Ball RevA- GS
$7,571.81
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 81.4 inches by 41.2 inches and an array layout of 4 wide by 3 high.
This mount fits on 2 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
| Weight | 1386.8200000000002 lbs |
|---|---|
| Dimensions | 90 × 24 × 24 in |
| SKU CODE | 2P-15-6TOP-HD-24-L-3HX4W-8584 |
| DUTY SIZE | HD |
| POLE SIZE | 6IN, PIPE, SCH, 40 |
| PRODUCT TYPE | BEAM |
| NUMBER OF POLES | 2.00 |
| POLE SPACING | 15.00 |
| POLE HEIGHT | 4.78 |
| WING SPAN | 24.00 |
| MAX FOUNDATION DEPTH | 6.25 |
| TILT ANGLE | 20.00 |
| CANTILEVER | 318.00 |
| GROUND CLEARANCE | 3.00 |
| NO POLES | 2.00 |
| MODULE AREA | 286.34 |
| ARRAY WIDTH | 27.47 |
| ARRAY HEIGHT | 10.43 |
| RAIL LENGTH | 125.10 |
| MODULE LENGTH | 81.40 |
| PASSED OVERHANG CHECK | TRUE |
| MODULE WIDTH GAP | 0.50 |
| MODULE LENGTH GAP | 1.00 |
| TOTAL FRAME LENGTH | 26.50 |
| GROUND TO TOP | 6.54 |
| PROJECTED PANEL HEIGHT | 3.52 |
| PROJECT ID | PR04310, LARRY, BALL, REVA-, GS |
| SITE ADDRESS | 2882, BALL, RD, CASSADAGA, NY, 14718, USA |
| MODULE WIDTH | 41.20 |
| NUMBER ROWS | 3.00 |
| NUMBER COLUMNS | 4.00 |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | C |
| FRAME DUTY OVERRIDE | AUTO |
| POLE OVERRIDE | AUTO |
| SOIL TYPE | SAND |
| CUSTOMER FOUNDATION OVERRIDE | 36, ROUND |
| FOUNDATION TYPE | ROUND |
| FOUNDATION SIZE | 36.00 |
| CHECK RAILS | FALSE |
| WIND SPEED OVERRIDE | 103.00 |
| SNOW LOAD OVERRIDE | 63.00 |
| DIRECT SNOW LOAD | FALSE |
| ADD ANGLE BRACE | FALSE |
| TOTAL PRICE | 7571.81 |
| TOTAL WEIGHT | 1386.82 |
| TOTAL PALLETS | 2.00 |
https://skycivquotes.s3.amazonaws.com/28f8a304-2d9d-4484-9331-8a62faa340c9.pdf |
|
| ID | 3340.00 |
| 3D Solar link |
