This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 73.7 inches by 40.6 inches and an array layout of 4 wide by 4 high.
This mount fits on 2 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
Solararrays30kw_RevA
$6,696.38
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 73.7 inches by 40.6 inches and an array layout of 4 wide by 4 high.
This mount fits on 2 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
Additional information
| Weight | 1322 lbs |
|---|---|
| Dimensions | 90 × 24 × 24 in |
https://solver.skyciv.com/temp/mergedpdf_erry3rqkdnkg80cs.php |
|
| SKU CODE | 2P-15-6TOP-SD-12-L-4Hx4W |
| DUTY SIZE | SD |
| POLE SIZE | 6in, Pipe, Sch, 40 |
| PRODUCT TYPE | Beam |
| NUMBER OF_POLES | 2 |
| POLE SPACING | 15 |
| POLE HEIGHT | 7.22 |
| WING SPAN | 12 |
| FOUNDATION DEPTHS | [object, Object] |
| TILT ANGLE | 38 |
| CANTILEVER | 294 |
| GROUND CLEARANCE | 3 |
| NO POLES | 2 |
| MODULE AREA | 341.13000000000005 |
| ARRAY WIDTH | 24.900000000000002 |
| ARRAY HEIGHT | 13.700000000000001 |
| RAIL LENGTH | 164.4 |
| MODULE LENGTH | 73.7 |
| PASSED OVERHANG_CHECK | true |
| MODULE WIDTH_GAP | 0.5 |
| MODULE LENGTH_GAP | 1 |
| TOTAL FRAME_LENGTH | 24.5 |
| GROUND TO_TOP | 11.383257089017711 |
| PROJECTED PANEL_HEIGHT | 8.331951966073907 |
| WIND SPEED_OVERRIDE | null |
| SNOW LOAD_OVERRIDE | null |
| DIRECT SNOW_LOAD | false |
| PROJECT ID | Solararrays30kw_RevA |
| SITE ADDRESS | 8, Country, Ln, Windsor, CT, 06095, USA |
| MODULE WIDTH | 40.6 |
| NUMBER ROWS | 4 |
| NUMBER COLUMNS | 4 |
| MAIN PIPE_SECTION | 2_12GA |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | B |
| SOIL TYPE | sand |
| FOUNDATION TYPE | Round |
| FOUNDATION SIZE | 36 |
| CHECK RAILS | true |
| TOTAL PRICE | 6696.380000000001 |
| TOTAL WEIGHT | 1155.38 |
| TOTAL PALLETS | 2 |
| ID | 178 |
