This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 65 inches by 40 inches and an array layout of 2 wide by 4 high.
This mount fits on 1 – 6in Pipe Sch 80 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
MTSOLAR_1ABJ06FAC3C8A
$3,169.90
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 65 inches by 40 inches and an array layout of 2 wide by 4 high.
This mount fits on 1 – 6in Pipe Sch 80 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
Weight | 527.44 lbs |
---|---|
Dimensions | 90 × 24 × 24 in |
SKU CODE | 1P-0-6TOP-SD-12-L-4HX2W-6LG0 |
DUTY SIZE | SD |
POLE SIZE | 6IN, PIPE, SCH, 80 |
PRODUCT TYPE | BEAM |
NUMBER OF POLES | 1.00 |
POLE SPACING | 0.00 |
POLE HEIGHT | 12.17 |
WING SPAN | 12.00 |
MAX FOUNDATION DEPTH | 6.75 |
TILT ANGLE | 50.00 |
CANTILEVER | 114.00 |
GROUND CLEARANCE | 7.00 |
NO POLES | 1.00 |
MODULE AREA | 148.50 |
ARRAY WIDTH | 11.00 |
ARRAY HEIGHT | 13.50 |
RAIL LENGTH | 162.00 |
MODULE LENGTH | 65.00 |
PASSED OVERHANG CHECK | TRUE |
MODULE WIDTH GAP | 0.50 |
MODULE LENGTH GAP | 1.00 |
TOTAL FRAME LENGTH | 9.50 |
GROUND TO TOP | 17.28 |
PROJECTED PANEL HEIGHT | 10.21 |
PROJECT ID | MTSOLAR, 1ABJ06FAC3C8A |
SITE ADDRESS | 405, DEFRANCE, WAY, GOLDEN, CO, 80401, USA |
MODULE WIDTH | 40.00 |
NUMBER ROWS | 4.00 |
NUMBER COLUMNS | 2.00 |
RISK CATEGORY | I |
EXPOSURE CATEGORY | C |
FRAME DUTY OVERRIDE | AUTO |
POLE OVERRIDE | AUTO |
SOIL TYPE | SAND |
CUSTOMER FOUNDATION OVERRIDE | 48, SQUARE |
FOUNDATION TYPE | SQUARE |
FOUNDATION SIZE | 48.00 |
CHECK RAILS | FALSE |
WIND SPEED OVERRIDE | 150.00 |
SNOW LOAD OVERRIDE | 30.00 |
DIRECT SNOW LOAD | TRUE |
ADD ANGLE BRACE | FALSE |
TOTAL PRICE | 3169.90 |
TOTAL WEIGHT | 527.44 |
TOTAL PALLETS | 1.00 |
