$7,507.90
This Pole Mount is designed for modules with dimensions of 67.8″ by 44.6″ and an array layout of 2 high by 6 wide.
This mount fits on 2 – 6″ Sch 80 steel poles with a spacing of 17′ (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
SKU: 2P-17-6TOP-SD-57-L-2Hx6W-H0EE
See 3D Model Here
This Pole Mount is designed for modules with dimensions of 67.8″ by 44.6″ and an array layout of 2 high by 6 wide.
This mount fits on 2 – 6″ Sch 80 steel poles with a spacing of 17′ (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
SKU: 2P-17-6TOP-SD-57-L-2Hx6W-H0EE
See 3D Model Here
| Weight | 849.3699999999999 lbs |
|---|---|
| Dimensions | 90 × 24 × 24 in |
| SKU CODE | 1P-0-10TOP-HD-57-L-4HX3W-A5IC |
| DUTY SIZE | HD |
| POLE SIZE | 10IN, PIPE, SCH, 80 |
| PRODUCT TYPE | BEAM |
| NUMBER OF POLES | 1.00 |
| POLE SPACING | 0.00 |
| POLE HEIGHT | 11.76 |
| WING SPAN | 57.00 |
| MAX FOUNDATION DEPTH | 9.00 |
| TILT ANGLE | 64.00 |
| CANTILEVER | 204.00 |
| GROUND CLEARANCE | 5.00 |
| NO POLES | 1.00 |
| MODULE AREA | 258.57 |
| ARRAY WIDTH | 17.20 |
| ARRAY HEIGHT | 15.03 |
| RAIL LENGTH | 180.40 |
| MODULE LENGTH | 67.80 |
| PASSED OVERHANG CHECK | TRUE |
| MODULE WIDTH GAP | 0.50 |
| MODULE LENGTH GAP | 1.00 |
| TOTAL FRAME LENGTH | 17.00 |
| GROUND TO TOP | 18.51 |
| PROJECTED PANEL HEIGHT | 13.51 |
| DESIGNER NAME | SAMUEL, LEGERE |
| DESIGNER EMAIL | |
| DESIGNER PHONE | 2077103747.00 |
| PROJECT ID | BEN, KINNEY, FINAL |
| SITE ADDRESS | 285, WESTERN, VW, LN, RUMFORD, ME, 04276, USA |
| MODULE WIDTH | 44.60 |
| NUMBER ROWS | 4.00 |
| NUMBER COLUMNS | 3.00 |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | B |
| FRAME DUTY OVERRIDE | AUTO |
| POLE OVERRIDE | AUTO |
| SOIL TYPE | SAND |
| CUSTOMER FOUNDATION OVERRIDE | 48, SQUARE |
| FOUNDATION TYPE | SQUARE |
| FOUNDATION SIZE | 48.00 |
| CHECK RAILS | FALSE |
| WIND SPEED OVERRIDE | 150.00 |
| SNOW LOAD OVERRIDE | 42.00 |
| DIRECT SNOW LOAD | FALSE |
| ADD ANGLE BRACE | FALSE |
| TOTAL PRICE | 4656.38 |
| TOTAL WEIGHT | 849.37 |
| TOTAL PALLETS | 1.00 |
