Frederickson_Res_23

$15,615.72

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 89.53 inches by 44.65 inches and an array layout of 10 wide by 3 high.
This mount fits on 4 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 19.75 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

SKU: 4P-19.75-6TOP-SD-45-L-3Hx10W-5LKJ Category:

Description

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 89.53 inches by 44.65 inches and an array layout of 10 wide by 3 high.
This mount fits on 4 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 19.75 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Additional information

Weight 2835.7 lbs
Dimensions 90 × 24 × 24 in
SKU CODE

4P-19.75-6TOP-SD-45-L-3HX10W-5LKJ

DUTY SIZE

SD

POLE SIZE

6IN, PIPE, SCH, 40

PRODUCT TYPE

BEAM

NUMBER OF POLES

4.00

POLE SPACING

19.75

POLE HEIGHT

6.24

WING SPAN

45.00

MAX FOUNDATION DEPTH

5.25

TILT ANGLE

35.00

CANTILEVER

891.00

GROUND CLEARANCE

3.00

NO POLES

4.00

MODULE AREA

851.55

ARRAY WIDTH

75.44

ARRAY HEIGHT

11.29

RAIL LENGTH

135.45

MODULE LENGTH

89.53

PASSED OVERHANG CHECK

TRUE

MODULE WIDTH GAP

0.50

MODULE LENGTH GAP

1.00

TOTAL FRAME LENGTH

74.25

GROUND TO TOP

9.44

PROJECTED PANEL HEIGHT

6.40

WIND SPEED OVERRIDE

NULL

SNOW LOAD OVERRIDE

NULL

DIRECT SNOW LOAD

FALSE

PROJECT ID

FREDERICKSON, RES, 23

SITE ADDRESS

6604, CANAL, RD, MANHATTAN, MT, 59741, USA

MODULE WIDTH

44.65

NUMBER ROWS

3.00

NUMBER COLUMNS

10.00

RISK CATEGORY

I

EXPOSURE CATEGORY

C

FRAME DUTY OVERRIDE

AUTO

POLE OVERRIDE

AUTO

SOIL TYPE

SAND

FOUNDATION TYPE

SQUARE

FOUNDATION SIZE

48.00

CHECK RAILS

FALSE

TOTAL PRICE

15615.72

TOTAL WEIGHT

2835.70

TOTAL PALLETS

4.00
