This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 68 inches by 44.7 inches and an array layout of 6 wide by 5 high.
This mount fits on 2 – 8in Pipe Sch 40 inch steel pole(s) with a spacing of 17 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
judy83462 – RevA – JB
$9,351.92
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 68 inches by 44.7 inches and an array layout of 6 wide by 5 high.
This mount fits on 2 – 8in Pipe Sch 40 inch steel pole(s) with a spacing of 17 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
Weight | 1838.6399999999999 lbs |
---|---|
Dimensions | 90 × 24 × 24 in |
SKU CODE | 2P-17-8TOP-SD-57-L-5HX6W-8H2G |
DUTY SIZE | SD |
POLE SIZE | 8IN, PIPE, SCH, 40 |
PRODUCT TYPE | BEAM |
NUMBER OF POLES | 2.00 |
POLE SPACING | 17.00 |
POLE HEIGHT | 11.53 |
WING SPAN | 57.00 |
MAX FOUNDATION DEPTH | 7.25 |
TILT ANGLE | 65.00 |
CANTILEVER | 408.00 |
GROUND CLEARANCE | 3.00 |
NO POLES | 2.00 |
MODULE AREA | 649.75 |
ARRAY WIDTH | 34.50 |
ARRAY HEIGHT | 18.83 |
RAIL LENGTH | 226.00 |
MODULE LENGTH | 68.00 |
PASSED OVERHANG CHECK | TRUE |
MODULE WIDTH GAP | 0.50 |
MODULE LENGTH GAP | 1.00 |
TOTAL FRAME LENGTH | 34.00 |
GROUND TO TOP | 19.97 |
PROJECTED PANEL HEIGHT | 16.88 |
PROJECT ID | JUDY83462, -, REVA, -, JB |
SITE ADDRESS | 8, HEATHER, LN, CARMEN, ID, 83462, USA |
MODULE WIDTH | 44.70 |
NUMBER ROWS | 5.00 |
NUMBER COLUMNS | 6.00 |
RISK CATEGORY | I |
EXPOSURE CATEGORY | B |
FRAME DUTY OVERRIDE | AUTO |
POLE OVERRIDE | AUTO |
SOIL TYPE | SAND |
CUSTOMER FOUNDATION OVERRIDE | 48, SQUARE |
FOUNDATION TYPE | SQUARE |
FOUNDATION SIZE | 48.00 |
CHECK RAILS | FALSE |
WIND SPEED OVERRIDE | 115.00 |
SNOW LOAD OVERRIDE | 20.00 |
DIRECT SNOW LOAD | FALSE |
ADD ANGLE BRACE | FALSE |
TOTAL PRICE | 9351.92 |
TOTAL WEIGHT | 1838.64 |
TOTAL PALLETS | 2.00 |
https://skycivquotes.s3.amazonaws.com/3a56a33c-7f32-4e32-870c-86d5d4f992c2.pdf |
|
ID | 5352.00 |
3D Solar link |
