This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 75.35 inches by 40.78 inches and an array layout of 5 wide by 3 high.
This mount fits on 2 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Lohman 3×5 400w 46D CUB
$7,124.64
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 75.35 inches by 40.78 inches and an array layout of 5 wide by 3 high.
This mount fits on 2 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
Weight | 1255.1 lbs |
---|---|
Dimensions | 90 × 24 × 24 in |
SKU CODE | 2P-15-6TOP-SD-45-L-3HX5W-H7JI |
DUTY SIZE | SD |
POLE SIZE | 6IN, PIPE, SCH, 40 |
PRODUCT TYPE | BEAM |
NUMBER OF POLES | 2.00 |
POLE SPACING | 15.00 |
POLE HEIGHT | 6.21 |
WING SPAN | 45.00 |
MAX FOUNDATION DEPTH | 5.50 |
TILT ANGLE | 46.00 |
CANTILEVER | 360.00 |
GROUND CLEARANCE | 2.50 |
NO POLES | 2.00 |
MODULE AREA | 328.31 |
ARRAY WIDTH | 31.81 |
ARRAY HEIGHT | 10.32 |
RAIL LENGTH | 123.84 |
MODULE LENGTH | 75.35 |
PASSED OVERHANG CHECK | TRUE |
MODULE WIDTH GAP | 0.50 |
MODULE LENGTH GAP | 1.00 |
TOTAL FRAME LENGTH | 30.00 |
GROUND TO TOP | 9.88 |
PROJECTED PANEL HEIGHT | 7.33 |
WIND SPEED OVERRIDE | 175.00 |
SNOW LOAD OVERRIDE | 55.00 |
DIRECT SNOW LOAD | FALSE |
ADD ANGLE BRACE | FALSE |
PROJECT ID | LOHMAN, 3X5, 400W, 46D, CUB |
SITE ADDRESS | 2000, CO, RD, 100, WARD, CO, 80481, USA |
MODULE WIDTH | 40.78 |
NUMBER ROWS | 3.00 |
NUMBER COLUMNS | 5.00 |
RISK CATEGORY | I |
EXPOSURE CATEGORY | C |
FRAME DUTY OVERRIDE | AUTO |
POLE OVERRIDE | AUTO |
SOIL TYPE | SAND |
CUSTOMER FOUNDATION OVERRIDE | 48, SQUARE |
FOUNDATION TYPE | SQUARE |
FOUNDATION SIZE | 48.00 |
CHECK RAILS | TRUE |
TOTAL PRICE | 7124.64 |
TOTAL WEIGHT | 1255.10 |
TOTAL PALLETS | 2.00 |
