This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 88.98 inches by 41.26 inches and an array layout of 6 wide by 5 high.
This mount fits on 3 – 10in Pipe Sch 40 inch steel pole(s) with a spacing of 17 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
PuschJane
$16,096.44
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 88.98 inches by 41.26 inches and an array layout of 6 wide by 5 high.
This mount fits on 3 – 10in Pipe Sch 40 inch steel pole(s) with a spacing of 17 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
| Weight | 3029.49 lbs |
|---|---|
| Dimensions | 90 × 24 × 24 in |
| SKU CODE | 3P-17-10TOP-XD-12-L-5HX6W-EB46 |
| DUTY SIZE | XD |
| POLE SIZE | 10IN, PIPE, SCH, 40 |
| PRODUCT TYPE | BEAM |
| NUMBER OF POLES | 3.00 |
| POLE SPACING | 17.00 |
| POLE HEIGHT | 10.98 |
| WING SPAN | 12.00 |
| MAX FOUNDATION DEPTH | 8.25 |
| TILT ANGLE | 20.00 |
| CANTILEVER | 522.00 |
| GROUND CLEARANCE | 8.00 |
| NO POLES | 3.00 |
| MODULE AREA | 782.83 |
| ARRAY WIDTH | 44.99 |
| ARRAY HEIGHT | 17.40 |
| RAIL LENGTH | 208.80 |
| MODULE LENGTH | 88.98 |
| PASSED OVERHANG CHECK | TRUE |
| MODULE WIDTH GAP | 0.50 |
| MODULE LENGTH GAP | 1.00 |
| TOTAL FRAME LENGTH | 43.50 |
| GROUND TO TOP | 13.92 |
| PROJECTED PANEL HEIGHT | 5.88 |
| PROJECT ID | PUSCHJANE |
| SITE ADDRESS | 200, HARVARD, PL, SYRACUSE, NY, 13210, USA |
| MODULE WIDTH | 41.26 |
| NUMBER ROWS | 5.00 |
| NUMBER COLUMNS | 6.00 |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | B |
| FRAME DUTY OVERRIDE | XD |
| POLE OVERRIDE | 10, 40 |
| SOIL TYPE | SAND |
| CUSTOMER FOUNDATION OVERRIDE | 36, ROUND |
| FOUNDATION TYPE | ROUND |
| FOUNDATION SIZE | 36.00 |
| CHECK RAILS | FALSE |
| WIND SPEED OVERRIDE | 109.00 |
| SNOW LOAD OVERRIDE | 50.00 |
| DIRECT SNOW LOAD | FALSE |
| ADD ANGLE BRACE | TRUE |
| TOTAL PRICE | 15329.94 |
| TOTAL WEIGHT | 3029.49 |
| TOTAL PALLETS | 3.00 |
