This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 74 inches by 41 inches and an array layout of 3 wide by 4 high.
This mount fits on 1 – 6in Pipe Sch 80 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
TOP12-74×41-115|40
$4,000.30
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 74 inches by 41 inches and an array layout of 3 wide by 4 high.
This mount fits on 1 – 6in Pipe Sch 80 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
Weight | 699.66 lbs |
---|---|
Dimensions | 90 × 24 × 24 in |
SKU CODE | 1P-0-6TOP-SD-57-L-4HX3W-GI23 |
DUTY SIZE | SD |
POLE SIZE | 6IN, PIPE, SCH, 80 |
PRODUCT TYPE | BEAM |
NUMBER OF POLES | 1.00 |
POLE SPACING | 0.00 |
POLE HEIGHT | 10.30 |
WING SPAN | 57.00 |
MAX FOUNDATION DEPTH | 6.50 |
TILT ANGLE | 50.00 |
CANTILEVER | 204.00 |
GROUND CLEARANCE | 5.00 |
NO POLES | 1.00 |
MODULE AREA | 259.38 |
ARRAY WIDTH | 18.75 |
ARRAY HEIGHT | 13.83 |
RAIL LENGTH | 166.00 |
MODULE LENGTH | 74.00 |
PASSED OVERHANG CHECK | TRUE |
MODULE WIDTH GAP | 0.50 |
MODULE LENGTH GAP | 1.00 |
TOTAL FRAME LENGTH | 17.00 |
GROUND TO TOP | 15.53 |
PROJECTED PANEL HEIGHT | 10.47 |
WIND SPEED OVERRIDE | 115.00 |
SNOW LOAD OVERRIDE | 40.00 |
DIRECT SNOW LOAD | FALSE |
ADD ANGLE BRACE | FALSE |
PROJECT ID | TOP12-74X41-115, 40 |
SITE ADDRESS | 54179, HERAK, RD, CHARLO, MT, 59824, USA |
MODULE WIDTH | 41.00 |
NUMBER ROWS | 4.00 |
NUMBER COLUMNS | 3.00 |
RISK CATEGORY | I |
EXPOSURE CATEGORY | C |
FRAME DUTY OVERRIDE | AUTO |
POLE OVERRIDE | AUTO |
SOIL TYPE | SAND |
CUSTOMER FOUNDATION OVERRIDE | 48, SQUARE |
FOUNDATION TYPE | SQUARE |
FOUNDATION SIZE | 48.00 |
CHECK RAILS | FALSE |
TOTAL PRICE | 4000.30 |
TOTAL WEIGHT | 699.66 |
TOTAL PALLETS | 1.00 |
https://skycivquotes.s3.amazonaws.com/36049df9-d2e7-45a5-be9e-a8d10acbd931.pdf |
|
ID | 5548.00 |
3D Solar link | |
MODULE NUMBER | 12 |
MODULE SIZE | 74×41 |
WIND SNOW LOAD | 115 mph, 40 psf |
