W-12398 v6

$6,683.84

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 67.7 inches by 44.6 inches and an array layout of 4 wide by 5 high.
This mount fits on 1 – 10in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Add a PE Stamped Drawing for this mount

For permitting, get a Professional Engineer's stamp on your construction drawing.

SKU: 1P-0-10TOP-XD-84-L-5Hx4W-IA98 Category:

Description

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 67.7 inches by 44.6 inches and an array layout of 4 wide by 5 high.
This mount fits on 1 – 10in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Additional information

Weight 1363.21 lbs
Dimensions 90 × 24 × 24 in
SKU CODE

1P-0-10TOP-XD-84-L-5HX4W-IA98

DUTY SIZE

XD

POLE SIZE

10IN, PIPE, SCH, 40

PRODUCT TYPE

BEAM

NUMBER OF POLES

1.00

POLE SPACING

0.00

POLE HEIGHT

13.14

WING SPAN

84.00

MAX FOUNDATION DEPTH

7.00

TILT ANGLE

60.00

CANTILEVER

258.00

GROUND CLEARANCE

5.00

NO POLES

1.00

MODULE AREA

430.33

ARRAY WIDTH

22.90

ARRAY HEIGHT

18.79

RAIL LENGTH

225.50

MODULE LENGTH

67.70

PASSED OVERHANG CHECK

TRUE

MODULE WIDTH GAP

0.50

MODULE LENGTH GAP

1.00

TOTAL FRAME LENGTH

21.50

GROUND TO TOP

21.18

PROJECTED PANEL HEIGHT

16.09

WIND SPEED OVERRIDE

105.00

SNOW LOAD OVERRIDE

75.00

DIRECT SNOW LOAD

FALSE

ADD ANGLE BRACE

FALSE

PROJECT ID

W-12398, V6

SITE ADDRESS

FRUITLAND, UT, 84027, USA

MODULE WIDTH

44.60

NUMBER ROWS

5.00

NUMBER COLUMNS

4.00

RISK CATEGORY

I

EXPOSURE CATEGORY

C

FRAME DUTY OVERRIDE

XD

POLE OVERRIDE

10, 40

SOIL TYPE

SANDY, GRAVEL

CUSTOMER FOUNDATION OVERRIDE

48, SQUARE

FOUNDATION TYPE

SQUARE

FOUNDATION SIZE

60.00

CHECK RAILS

TRUE

TOTAL PRICE

6683.84

TOTAL WEIGHT

1363.21

TOTAL PALLETS

1.00

pdf

https://skycivquotes.s3.amazonaws.com/d4198c92-8634-4a12-9b48-80dfa35d6d75.pdf

ID

6643.00
