This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 71.34 inches by 41.18 inches and an array layout of 10 wide by 5 high.
This mount fits on 3 – 10in Pipe Sch 40 inch steel pole(s) with a spacing of 22.5 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
YurtCarport-RevA
$19,789.61
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 71.34 inches by 41.18 inches and an array layout of 10 wide by 5 high.
This mount fits on 3 – 10in Pipe Sch 40 inch steel pole(s) with a spacing of 22.5 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
| Weight | 3831.25 lbs |
|---|---|
| Dimensions | 90 × 24 × 24 in |
| SKU CODE | 3P-22.5-10TOP-XD-45-L-5HX10W-G28B |
| DUTY SIZE | XD |
| POLE SIZE | 10IN, PIPE, SCH, 40 |
| PRODUCT TYPE | BEAM |
| NUMBER OF POLES | 3.00 |
| POLE SPACING | 22.50 |
| POLE HEIGHT | 17.52 |
| WING SPAN | 45.00 |
| MAX FOUNDATION DEPTH | 15.00 |
| TILT ANGLE | 60.00 |
| CANTILEVER | 720.00 |
| GROUND CLEARANCE | 10.00 |
| NO POLES | 3.00 |
| MODULE AREA | 1046.92 |
| ARRAY WIDTH | 60.28 |
| ARRAY HEIGHT | 17.37 |
| RAIL LENGTH | 208.40 |
| MODULE LENGTH | 71.34 |
| PASSED OVERHANG CHECK | TRUE |
| MODULE WIDTH GAP | 0.50 |
| MODULE LENGTH GAP | 1.00 |
| TOTAL FRAME LENGTH | 60.00 |
| GROUND TO TOP | 24.95 |
| PROJECTED PANEL HEIGHT | 14.86 |
| PROJECT ID | YURTCARPORT-REVA |
| SITE ADDRESS | 10584, N, BASIN, CYN, RD, PARK, CITY, UT, 84098, USA |
| MODULE WIDTH | 41.18 |
| NUMBER ROWS | 5.00 |
| NUMBER COLUMNS | 10.00 |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | B |
| FRAME DUTY OVERRIDE | XD |
| POLE OVERRIDE | 10, 40 |
| SOIL TYPE | SAND |
| FOUNDATION TYPE | ROUND |
| FOUNDATION SIZE | 36.00 |
| CHECK RAILS | TRUE |
| WIND SPEED OVERRIDE | 97.00 |
| SNOW LOAD OVERRIDE | 213.00 |
| DIRECT SNOW LOAD | FALSE |
| TOTAL PRICE | 18847.25 |
| TOTAL WEIGHT | 3831.25 |
| TOTAL PALLETS | 3.00 |
