This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 78.27 inches by 39.53 inches and an array layout of 3 wide by 4 high.
This mount fits on 1 – 12in Sch 40 steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Bald Hills RevB- GS
$5,169.22
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 78.27 inches by 39.53 inches and an array layout of 3 wide by 4 high.
This mount fits on 1 – 12in Sch 40 steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
| Weight | 899.3299999999999 lbs |
|---|---|
| Dimensions | 90 × 24 × 24 in |
| SKU CODE | 1P-0-10TOP-HD-72-L-4HX3W-GAC3 |
| DUTY SIZE | HD |
| POLE SIZE | 10IN, PIPE, SCH, 40 |
| PRODUCT TYPE | BEAM |
| NUMBER OF POLES | 1.00 |
| POLE SPACING | 0.00 |
| POLE HEIGHT | 8.34 |
| WING SPAN | 72.00 |
| MAX FOUNDATION DEPTH | 6.75 |
| TILT ANGLE | 30.00 |
| CANTILEVER | 234.00 |
| GROUND CLEARANCE | 5.00 |
| NO POLES | 1.00 |
| MODULE AREA | 264.43 |
| ARRAY WIDTH | 19.82 |
| ARRAY HEIGHT | 13.34 |
| RAIL LENGTH | 160.12 |
| MODULE LENGTH | 78.27 |
| PASSED OVERHANG CHECK | TRUE |
| MODULE WIDTH GAP | 0.50 |
| MODULE LENGTH GAP | 1.00 |
| TOTAL FRAME LENGTH | 19.50 |
| GROUND TO TOP | 11.63 |
| PROJECTED PANEL HEIGHT | 6.59 |
| WIND SPEED OVERRIDE | 120.00 |
| SNOW LOAD OVERRIDE | 30.00 |
| DIRECT SNOW LOAD | FALSE |
| ADD ANGLE BRACE | FALSE |
| PROJECT ID | BALD, HILLS, REVB-, GS |
| SITE ADDRESS | WASHINGTON, USA |
| MODULE WIDTH | 39.53 |
| NUMBER ROWS | 4.00 |
| NUMBER COLUMNS | 3.00 |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | C |
| FRAME DUTY OVERRIDE | AUTO |
| POLE OVERRIDE | 10, 40 |
| SOIL TYPE | SAND |
| CUSTOMER FOUNDATION OVERRIDE | 48, SQUARE |
| FOUNDATION TYPE | SQUARE |
| FOUNDATION SIZE | 48.00 |
| CHECK RAILS | FALSE |
| TOTAL PRICE | 4847.80 |
| TOTAL WEIGHT | 899.33 |
| TOTAL PALLETS | 1.00 |
