This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 64 inches by 44 inches and an array layout of 2 wide by 3 high.
This mount fits on 1 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
GoodEnergySolar PeachTree
$3,063.76
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 64 inches by 44 inches and an array layout of 2 wide by 3 high.
This mount fits on 1 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
Weight | 512.84 lbs |
---|---|
Dimensions | 90 × 24 × 24 in |
SKU CODE | 1P-0-6TOP-SD-12-L-3HX2W-LCG4 |
DUTY SIZE | SD |
POLE SIZE | 6IN, PIPE, SCH, 40 |
PRODUCT TYPE | BEAM |
NUMBER OF POLES | 1.00 |
POLE SPACING | 0.00 |
POLE HEIGHT | 8.04 |
WING SPAN | 12.00 |
MAX FOUNDATION DEPTH | 4.00 |
TILT ANGLE | 65.00 |
CANTILEVER | 114.00 |
GROUND CLEARANCE | 3.00 |
NO POLES | 1.00 |
MODULE AREA | 120.52 |
ARRAY WIDTH | 10.83 |
ARRAY HEIGHT | 11.13 |
RAIL LENGTH | 133.50 |
MODULE LENGTH | 64.00 |
PASSED OVERHANG CHECK | TRUE |
MODULE WIDTH GAP | 0.50 |
MODULE LENGTH GAP | 1.00 |
TOTAL FRAME LENGTH | 9.50 |
GROUND TO TOP | 13.03 |
PROJECTED PANEL HEIGHT | 9.97 |
WIND SPEED OVERRIDE | 88.00 |
SNOW LOAD OVERRIDE | NULL |
DIRECT SNOW LOAD | FALSE |
PROJECT ID | GOODENERGYSOLAR, PEACHTREE |
SITE ADDRESS | LOS, PADRES, NATIONAL, FOREST, SUPERVISOR'S, OFFICE, (HEADQUARTERS), 1980, OLD, MISSION, DR, SOLVANG, CA, 93463, USA |
MODULE WIDTH | 44.00 |
NUMBER ROWS | 3.00 |
NUMBER COLUMNS | 2.00 |
RISK CATEGORY | I |
EXPOSURE CATEGORY | B |
FRAME DUTY OVERRIDE | AUTO |
POLE OVERRIDE | AUTO |
SOIL TYPE | SAND |
FOUNDATION TYPE | SQUARE |
FOUNDATION SIZE | 48.00 |
CHECK RAILS | TRUE |
TOTAL PRICE | 3063.76 |
TOTAL WEIGHT | 512.84 |
TOTAL PALLETS | 1.00 |
https://skycivquotes.s3.amazonaws.com/873b3fcd-672c-418a-a227-b9ba98340c5e.pdf |
|
ID | 1420.00 |
3D Solar link |
