This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 93.77957819999999 inches by 44.6456934 inches and an array layout of 4 wide by 5 high.
This mount fits on 2 – 8in Pipe Sch 80 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Kentville Farm Project CA Calcs 5×4 46deg – V1Jb
$9,320.19
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 93.77957819999999 inches by 44.6456934 inches and an array layout of 4 wide by 5 high.
This mount fits on 2 – 8in Pipe Sch 80 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
| Weight | 1772.8600000000001 lbs |
|---|---|
| Dimensions | 90 × 24 × 24 in |
| SKU CODE | 2P-15-8TOP-HD-45-L-5HX4W-D7BL |
| DUTY SIZE | HD |
| POLE SIZE | 8IN, PIPE, SCH, 80 |
| PRODUCT TYPE | BEAM |
| NUMBER OF POLES | 2.00 |
| POLE SPACING | 15.00 |
| POLE HEIGHT | 12.67 |
| WING SPAN | 45.00 |
| MAX FOUNDATION DEPTH | 0.00 |
| TILT ANGLE | 46.00 |
| CANTILEVER | 360.00 |
| GROUND CLEARANCE | 5.91 |
| NO POLES | 2.00 |
| MODULE AREA | 594.29 |
| ARRAY WIDTH | 31.59 |
| ARRAY HEIGHT | 18.81 |
| RAIL LENGTH | 225.73 |
| MODULE LENGTH | 93.78 |
| PASSED OVERHANG CHECK | TRUE |
| MODULE WIDTH GAP | 0.50 |
| MODULE LENGTH GAP | 1.00 |
| TOTAL FRAME LENGTH | 30.00 |
| GROUND TO TOP | 19.44 |
| PROJECTED PANEL HEIGHT | 13.53 |
| DESIGNER NAME | |
| DESIGNER EMAIL | |
| DESIGNER PHONE | |
| PROJECT ID | KENTVILLE, FARM, PROJECT, CA, CALCS, 5X4, 46DEG, -, V1JB |
| SITE ADDRESS | KENTVILLE, NS, CANADA |
| MODULE INFO | |
| MODULE WIDTH | 44.65 |
| NUMBER ROWS | 5.00 |
| NUMBER COLUMNS | 4.00 |
| RECURRENCE INTERVAL | 50, YEARS |
| IMPORTANCE CATEGORY | LOW |
| TERRAIN CAT CAN | A |
| AREA CLASSIFICATION | RURAL |
| FRAME DUTY OVERRIDE | AUTO |
| POLE OVERRIDE | AUTO |
| SOIL TYPE | SAND |
| CUSTOMER FOUNDATION OVERRIDE | 48, SQUARE |
| FOUNDATION TYPE | SQUARE |
| FOUNDATION SIZE | 48.00 |
| CHECK RAILS | TRUE |
| WIND SPEED OVERRIDE | NULL |
| SNOW LOAD OVERRIDE | NULL |
| ADD ANGLE BRACE | FALSE |
| TOTAL PRICE | 9320.19 |
| TOTAL WEIGHT | 1772.86 |
| TOTAL PALLETS | 2.00 |
https://skycivquotes.s3.amazonaws.com/0dfcdd99-5395-46dd-8a2b-f9d04a7a1cc4.pdf |
|
| ID | 13643.00 |
| 3D Solar link |
