This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 90 inches by 42 inches and an array layout of 2 wide by 4 high.
This mount fits on 1 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
MichaelBugola|Option1|8panels-JB-RevD
$3,553.00
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 90 inches by 42 inches and an array layout of 2 wide by 4 high.
This mount fits on 1 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
Weight | 626.44 lbs |
---|---|
Dimensions | 90 × 24 × 24 in |
SKU CODE | 1P-0-6TOP-SD-45-L-4HX2W-4FG0 |
DUTY SIZE | SD |
POLE SIZE | 6IN, PIPE, SCH, 40 |
PRODUCT TYPE | BEAM |
NUMBER OF POLES | 1.00 |
POLE SPACING | 0.00 |
POLE HEIGHT | 9.54 |
WING SPAN | 45.00 |
MAX FOUNDATION DEPTH | 6.50 |
TILT ANGLE | 30.00 |
CANTILEVER | 180.00 |
GROUND CLEARANCE | 6.00 |
NO POLES | 1.00 |
MODULE AREA | 214.86 |
ARRAY WIDTH | 15.17 |
ARRAY HEIGHT | 14.17 |
RAIL LENGTH | 170.00 |
MODULE LENGTH | 90.00 |
PASSED OVERHANG CHECK | TRUE |
MODULE WIDTH GAP | 0.50 |
MODULE LENGTH GAP | 1.00 |
TOTAL FRAME LENGTH | 15.00 |
GROUND TO TOP | 13.04 |
PROJECTED PANEL HEIGHT | 7.00 |
WIND SPEED OVERRIDE | 107.00 |
SNOW LOAD OVERRIDE | 30.00 |
DIRECT SNOW LOAD | FALSE |
PROJECT ID | MICHAELBUGOLA, OPTION1, 8PANELS-JB-REVD |
SITE ADDRESS | 3030, FS, RD, 73, PRESCOTT, AZ, 86303, USA |
MODULE WIDTH | 42.00 |
NUMBER ROWS | 4.00 |
NUMBER COLUMNS | 2.00 |
RISK CATEGORY | I |
EXPOSURE CATEGORY | B |
FRAME DUTY OVERRIDE | AUTO |
POLE OVERRIDE | AUTO |
SOIL TYPE | SAND |
CUSTOMER FOUNDATION OVERRIDE | 48, SQUARE |
FOUNDATION TYPE | ROUND |
FOUNDATION SIZE | 54.00 |
CHECK RAILS | TRUE |
TOTAL PRICE | 3553.00 |
TOTAL WEIGHT | 626.44 |
TOTAL PALLETS | 1.00 |
https://skycivquotes.s3.amazonaws.com/1fc122af-4d04-4610-ace5-ccabb64e2ba0.pdf |
|
ID | 2609.00 |
3D Solar link |
