This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 79 inches by 39 inches and an array layout of 10 wide by 3 high.
This mount fits on 4 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 17 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Add a PE Stamped Drawing for this mount

For permitting, get a Professional Engineer's stamp on your construction drawing.

SKU: 4P-17-6TOP-XD-45-L-3Hx10W-I4K5 Category:

Description

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 79 inches by 39 inches and an array layout of 10 wide by 3 high.
This mount fits on 4 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 17 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Additional information

Weight 3610.2 lbs
Dimensions 90 × 24 × 24 in
SKU CODE

4P-17-6TOP-XD-45-L-3HX10W-I4K5

DUTY SIZE

XD

POLE SIZE

6IN, PIPE, SCH, 40

PRODUCT TYPE

BEAM

NUMBER OF POLES

4.00

POLE SPACING

17.00

POLE HEIGHT

9.28

WING SPAN

45.00

MAX FOUNDATION DEPTH

4.75

TILT ANGLE

15.00

CANTILEVER

792.00

GROUND CLEARANCE

8.00

NO POLES

4.00

MODULE AREA

658.33

ARRAY WIDTH

66.67

ARRAY HEIGHT

9.88

RAIL LENGTH

118.50

MODULE LENGTH

79.00

PASSED OVERHANG CHECK

TRUE

MODULE WIDTH GAP

0.50

MODULE LENGTH GAP

1.00

TOTAL FRAME LENGTH

66.00

GROUND TO TOP

10.54

PROJECTED PANEL HEIGHT

2.52

WIND SPEED OVERRIDE

NULL

SNOW LOAD OVERRIDE

NULL

DIRECT SNOW LOAD

FALSE

ADD ANGLE BRACE

FALSE

PROJECT ID

MTSOLAR, 0851L6G3KFH0G

SITE ADDRESS

705, 2ND, AVE, W, MCLAUGHLIN, SD, 57642, USA

MODULE WIDTH

39.00

NUMBER ROWS

3.00

NUMBER COLUMNS

10.00

RISK CATEGORY

I

EXPOSURE CATEGORY

C

FRAME DUTY OVERRIDE

AUTO

POLE OVERRIDE

AUTO

SOIL TYPE

SAND

CUSTOMER FOUNDATION OVERRIDE

48, SQUARE

FOUNDATION TYPE

SQUARE

FOUNDATION SIZE

48.00

CHECK RAILS

FALSE

TOTAL PRICE

19250.27

TOTAL WEIGHT

3610.20

TOTAL PALLETS

4.00
