MTSOLAR_3FC249E6CL56G

$4,171.28

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 78 inches by 40 inches and an array layout of 3 wide by 4 high.
This mount fits on 1 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

SKU: 1P-0-6TOP-SD-72-L-4Hx3W-BL61 Category:

Description

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 78 inches by 40 inches and an array layout of 3 wide by 4 high.
This mount fits on 1 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Additional information

Weight 744.66 lbs
Dimensions 90 × 24 × 24 in
SKU CODE

1P-0-6TOP-SD-72-L-4HX3W-BL61

DUTY SIZE

SD

POLE SIZE

6IN, PIPE, SCH, 40

PRODUCT TYPE

BEAM

NUMBER OF POLES

1.00

POLE SPACING

0.00

POLE HEIGHT

6.77

WING SPAN

72.00

MAX FOUNDATION DEPTH

5.50

TILT ANGLE

45.00

CANTILEVER

234.00

GROUND CLEARANCE

2.00

NO POLES

1.00

MODULE AREA

266.63

ARRAY WIDTH

19.75

ARRAY HEIGHT

13.50

RAIL LENGTH

162.00

MODULE LENGTH

78.00

PASSED OVERHANG CHECK

TRUE

MODULE WIDTH GAP

0.50

MODULE LENGTH GAP

1.00

TOTAL FRAME LENGTH

19.50

GROUND TO TOP

11.49

PROJECTED PANEL HEIGHT

9.43

WIND SPEED OVERRIDE

NULL

SNOW LOAD OVERRIDE

NULL

DIRECT SNOW LOAD

FALSE

PROJECT ID

MTSOLAR, 3FC249E6CL56G

SITE ADDRESS

5, N, PROVIDENCE, RD, COLUMBIA, MO, 65203, USA

MODULE WIDTH

40.00

NUMBER ROWS

4.00

NUMBER COLUMNS

3.00

RISK CATEGORY

I

EXPOSURE CATEGORY

B

FRAME DUTY OVERRIDE

AUTO

POLE OVERRIDE

AUTO

SOIL TYPE

SAND

FOUNDATION TYPE

SQUARE

FOUNDATION SIZE

48.00

CHECK RAILS

FALSE

TOTAL PRICE

4171.28

TOTAL WEIGHT

744.66

TOTAL PALLETS

1.00
