This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 63 inches by 41 inches and an array layout of 14 wide by 5 high.
This mount fits on 4 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 19.75 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
MTSOLAR_491C2J7BIHKK
$19,949.90
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 63 inches by 41 inches and an array layout of 14 wide by 5 high.
This mount fits on 4 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 19.75 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
Weight | 3956.66 lbs |
---|---|
Dimensions | 90 × 24 × 24 in |
SKU CODE | 4P-19.75-6TOP-SD-45-L-5HX14W-G6CK |
DUTY SIZE | SD |
POLE SIZE | 6IN, PIPE, SCH, 40 |
PRODUCT TYPE | BEAM |
NUMBER OF POLES | 4.00 |
POLE SPACING | 19.75 |
POLE HEIGHT | 12.00 |
WING SPAN | 45.00 |
MAX FOUNDATION DEPTH | 6.25 |
TILT ANGLE | 0.00 |
CANTILEVER | 891.00 |
GROUND CLEARANCE | 12.00 |
NO POLES | 4.00 |
MODULE AREA | 1291.11 |
ARRAY WIDTH | 74.67 |
ARRAY HEIGHT | 17.29 |
RAIL LENGTH | 207.50 |
MODULE LENGTH | 63.00 |
PASSED OVERHANG CHECK | TRUE |
MODULE WIDTH GAP | 0.50 |
MODULE LENGTH GAP | 1.00 |
TOTAL FRAME LENGTH | 74.25 |
GROUND TO TOP | 12.00 |
PROJECTED PANEL HEIGHT | 0.00 |
WIND SPEED OVERRIDE | NULL |
SNOW LOAD OVERRIDE | NULL |
DIRECT SNOW LOAD | FALSE |
ADD ANGLE BRACE | FALSE |
PROJECT ID | MTSOLAR, 491C2J7BIHKK |
SITE ADDRESS | 201, PARKWAY, W, DUNCAN, SC, 29334, USA |
MODULE WIDTH | 41.00 |
NUMBER ROWS | 5.00 |
NUMBER COLUMNS | 14.00 |
RISK CATEGORY | I |
EXPOSURE CATEGORY | C |
FRAME DUTY OVERRIDE | AUTO |
POLE OVERRIDE | AUTO |
SOIL TYPE | SAND |
CUSTOMER FOUNDATION OVERRIDE | 36, ROUND |
FOUNDATION TYPE | ROUND |
FOUNDATION SIZE | 36.00 |
CHECK RAILS | FALSE |
TOTAL PRICE | 19949.90 |
TOTAL WEIGHT | 3956.66 |
TOTAL PALLETS | 4.00 |
