MTSOLAR_8285K949JBJI

$16,604.35

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 69 inches by 40.9 inches and an array layout of 10 wide by 5 high.
This mount fits on 3 – 8in Pipe Sch 80 inch steel pole(s) with a spacing of 19.75 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

SKU: 3P-19.75-8TOP-HD-57-L-5Hx10W-FE8H Category:

Description

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 69 inches by 40.9 inches and an array layout of 10 wide by 5 high.
This mount fits on 3 – 8in Pipe Sch 80 inch steel pole(s) with a spacing of 19.75 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Additional information

Weight 3350.09 lbs
Dimensions 90 × 24 × 24 in
SKU CODE

3P-19.75-8TOP-HD-57-L-5HX10W-FE8H

DUTY SIZE

HD

POLE SIZE

8IN, PIPE, SCH, 80

PRODUCT TYPE

BEAM

NUMBER OF POLES

3.00

POLE SPACING

19.75

POLE HEIGHT

12.77

WING SPAN

57.00

MAX FOUNDATION DEPTH

8.00

TILT ANGLE

42.00

CANTILEVER

678.00

GROUND CLEARANCE

7.00

NO POLES

3.00

MODULE AREA

1006.25

ARRAY WIDTH

58.33

ARRAY HEIGHT

17.25

RAIL LENGTH

207.00

MODULE LENGTH

69.00

PASSED OVERHANG CHECK

TRUE

MODULE WIDTH GAP

0.50

MODULE LENGTH GAP

1.00

TOTAL FRAME LENGTH

56.50

GROUND TO TOP

18.47

PROJECTED PANEL HEIGHT

11.40

WIND SPEED OVERRIDE

NULL

SNOW LOAD OVERRIDE

NULL

DIRECT SNOW LOAD

FALSE

PROJECT ID

MTSOLAR, 8285K949JBJI

SITE ADDRESS

353, FAIRFIELD, RD, FREEHOLD, NJ, 07728, USA

MODULE WIDTH

40.90

NUMBER ROWS

5.00

NUMBER COLUMNS

10.00

RISK CATEGORY

I

EXPOSURE CATEGORY

B

FRAME DUTY OVERRIDE

AUTO

POLE OVERRIDE

AUTO

SOIL TYPE

SAND

FOUNDATION TYPE

SQUARE

FOUNDATION SIZE

48.00

CHECK RAILS

FALSE

TOTAL PRICE

16604.35

TOTAL WEIGHT

3350.09

TOTAL PALLETS

3.00
