This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 69.4 inches by 40.8 inches and an array layout of 3 wide by 5 high.
This mount fits on 1 – 8in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Reduce Global Warming C
$5,128.81
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 69.4 inches by 40.8 inches and an array layout of 3 wide by 5 high.
This mount fits on 1 – 8in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
Weight | 1027.03 lbs |
---|---|
Dimensions | 90 × 24 × 24 in |
SKU CODE | 1P-0-8TOP-HD-57-L-5HX3W-JE19 |
DUTY SIZE | HD |
POLE SIZE | 8IN, PIPE, SCH, 40 |
PRODUCT TYPE | BEAM |
NUMBER OF POLES | 1.00 |
POLE SPACING | 0.00 |
POLE HEIGHT | 11.59 |
WING SPAN | 57.00 |
MAX FOUNDATION DEPTH | 6.00 |
TILT ANGLE | 50.00 |
CANTILEVER | 204.00 |
GROUND CLEARANCE | 5.00 |
NO POLES | 1.00 |
MODULE AREA | 302.87 |
ARRAY WIDTH | 17.60 |
ARRAY HEIGHT | 17.21 |
RAIL LENGTH | 206.50 |
MODULE LENGTH | 69.40 |
PASSED OVERHANG CHECK | TRUE |
MODULE WIDTH GAP | 0.50 |
MODULE LENGTH GAP | 1.00 |
TOTAL FRAME LENGTH | 17.00 |
GROUND TO TOP | 18.10 |
PROJECTED PANEL HEIGHT | 13.02 |
PROJECT ID | REDUCE, GLOBAL, WARMING, C |
SITE ADDRESS | 42, BEECH, LN, BETHEL, ME, 04217, USA |
MODULE WIDTH | 40.80 |
NUMBER ROWS | 5.00 |
NUMBER COLUMNS | 3.00 |
RISK CATEGORY | I |
EXPOSURE CATEGORY | B |
FRAME DUTY OVERRIDE | AUTO |
POLE OVERRIDE | 8, 40 |
SOIL TYPE | SAND |
FOUNDATION TYPE | SQUARE |
FOUNDATION SIZE | 48.00 |
CHECK RAILS | FALSE |
WIND SPEED OVERRIDE | 99.00 |
SNOW LOAD OVERRIDE | 101.00 |
DIRECT SNOW LOAD | FALSE |
TOTAL PRICE | 5128.81 |
TOTAL WEIGHT | 1027.03 |
TOTAL PALLETS | 1.00 |
