This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 65 inches by 40 inches and an array layout of 3 wide by 4 high.
This mount fits on 1 – 8in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
SKYSOLAR_94G9E59L00DF
$2,625.27
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 65 inches by 40 inches and an array layout of 3 wide by 4 high.
This mount fits on 1 – 8in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
Weight | 794.37 lbs |
---|---|
Dimensions | 90 × 24 × 24 in |
https%3A%2F%2Fsolver.skyciv.com%2Ftemp%2Fmergedpdf_fnuvtoc9tbksksg0.php |
|
SKU CODE | 1P-0-8TOP-HD-45-L-4HX3W |
DUTY SIZE | HD |
POLE SIZE | 8IN, PIPE, SCH, 40 |
PRODUCT TYPE | BEAM |
NUMBER OF POLES | 1.00 |
POLE SPACING | 15.00 |
POLE HEIGHT | 8.38 |
WING SPAN | 45.00 |
FOUNDATION DEPTHS | [OBJECT, OBJECT] |
TILT ANGLE | 30.00 |
CANTILEVER | 180.00 |
GROUND CLEARANCE | 5.00 |
NO POLES | 1.00 |
MODULE AREA | 222.75 |
ARRAY WIDTH | 16.50 |
ARRAY HEIGHT | 13.50 |
RAIL LENGTH | 162.00 |
MODULE LENGTH | 65.00 |
PASSED OVERHANG CHECK | TRUE |
MODULE WIDTH GAP | 0.50 |
MODULE LENGTH GAP | 1.00 |
TOTAL FRAME LENGTH | 15.00 |
GROUND TO TOP | 11.71 |
PROJECTED PANEL HEIGHT | 6.67 |
WIND SPEED OVERRIDE | NULL |
SNOW LOAD OVERRIDE | NULL |
DIRECT SNOW LOAD | FALSE |
PROJECT ID | SKYSOLAR, 94G9E59L00DF |
SITE ADDRESS | BOSTON, MA, USA |
MODULE WIDTH | 40.00 |
NUMBER ROWS | 4.00 |
NUMBER COLUMNS | 3.00 |
MAIN PIPE SECTION | 2, 12GA |
RISK CATEGORY | I |
EXPOSURE CATEGORY | C |
SOIL TYPE | SAND |
FOUNDATION TYPE | SQUARE |
FOUNDATION SIZE | 48.00 |
CHECK RAILS | FALSE |
TOTAL PRICE | 2625.27 |
TOTAL WEIGHT | 794.37 |
TOTAL PALLETS | 1.00 |
ID | 61.00 |
