BLR_35_400

$11,330.82

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 67.756 inches by 44.6 inches and an array layout of 7 wide by 5 high.
This mount fits on 2 – 8in Pipe Sch 80 inch steel pole(s) with a spacing of 22.5 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

SKU: 2P-22.5-8TOP-HD-57-L-5Hx7W-STRUTS-FAJF Category:

Description

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 67.756 inches by 44.6 inches and an array layout of 7 wide by 5 high.
This mount fits on 2 – 8in Pipe Sch 80 inch steel pole(s) with a spacing of 22.5 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Additional information

Weight 2294.26 lbs
Dimensions 90 × 24 × 24 in
SKU CODE

2P-22.5-8TOP-HD-57-L-5HX7W-STRUTS-FAJF

DUTY SIZE

HD

POLE SIZE

8IN, PIPE, SCH, 80

PRODUCT TYPE

BEAM

NUMBER OF POLES

2.00

POLE SPACING

22.50

POLE HEIGHT

10.79

WING SPAN

57.00

MAX FOUNDATION DEPTH

7.50

TILT ANGLE

56.00

CANTILEVER

474.00

GROUND CLEARANCE

3.00

NO POLES

2.00

MODULE AREA

753.69

ARRAY WIDTH

40.11

ARRAY HEIGHT

18.79

RAIL LENGTH

225.50

MODULE LENGTH

67.76

PASSED OVERHANG CHECK

TRUE

MODULE WIDTH GAP

0.50

MODULE LENGTH GAP

1.00

TOTAL FRAME LENGTH

39.50

GROUND TO TOP

18.49

PROJECTED PANEL HEIGHT

15.41

PROJECT ID

BLR, 35, 400

SITE ADDRESS

16, BEULAH, LAND, RD, BLANDFORD, MA, 01008, USA

MODULE WIDTH

44.60

NUMBER ROWS

5.00

NUMBER COLUMNS

7.00

RISK CATEGORY

I

EXPOSURE CATEGORY

C

FRAME DUTY OVERRIDE

AUTO

POLE OVERRIDE

AUTO

SOIL TYPE

SAND

CUSTOMER FOUNDATION OVERRIDE

48, SQUARE

FOUNDATION TYPE

SQUARE

FOUNDATION SIZE

48.00

CHECK RAILS

FALSE

WIND SPEED OVERRIDE

105.00

SNOW LOAD OVERRIDE

88.00

DIRECT SNOW LOAD

FALSE

ADD ANGLE BRACE

TRUE

TOTAL PRICE

11330.82

TOTAL WEIGHT

2294.26

TOTAL PALLETS

2.00
