Brush – clay|square – V1Jb

$9,368.94

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 71.7 inches by 40 inches and an array layout of 6 wide by 4 high.
This mount fits on 2 – 8in Pipe Sch 80 inch steel pole(s) with a spacing of 19.75 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

SKU: 2P-19.75-8TOP-HD-45-L-4Hx6W-C109 Category:

Description

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 71.7 inches by 40 inches and an array layout of 6 wide by 4 high.
This mount fits on 2 – 8in Pipe Sch 80 inch steel pole(s) with a spacing of 19.75 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Additional information

Weight 1712.52 lbs
Dimensions 90 × 24 × 24 in
SKU CODE

2P-19.75-8TOP-HD-45-L-4HX6W-C109

DUTY SIZE

HD

POLE SIZE

8IN, PIPE, SCH, 80

PRODUCT TYPE

BEAM

NUMBER OF POLES

2.00

POLE SPACING

19.75

POLE HEIGHT

9.77

WING SPAN

45.00

MAX FOUNDATION DEPTH

8.25

TILT ANGLE

45.00

CANTILEVER

417.00

GROUND CLEARANCE

5.00

NO POLES

2.00

MODULE AREA

490.73

ARRAY WIDTH

36.35

ARRAY HEIGHT

13.50

RAIL LENGTH

162.00

MODULE LENGTH

71.70

PASSED OVERHANG CHECK

TRUE

MODULE WIDTH GAP

0.50

MODULE LENGTH GAP

1.00

TOTAL FRAME LENGTH

34.75

GROUND TO TOP

14.49

PROJECTED PANEL HEIGHT

9.43

WIND SPEED OVERRIDE

115.00

SNOW LOAD OVERRIDE

30.00

DIRECT SNOW LOAD

FALSE

ADD ANGLE BRACE

FALSE

PROJECT ID

BRUSH, -, CLAY, SQUARE, -, V1JB

SITE ADDRESS

5620, LOST, DR, ROANOKE, VA, 24018, USA

MODULE WIDTH

40.00

NUMBER ROWS

4.00

NUMBER COLUMNS

6.00

RISK CATEGORY

I

EXPOSURE CATEGORY

C

FRAME DUTY OVERRIDE

AUTO

POLE OVERRIDE

AUTO

SOIL TYPE

CLAY

CUSTOMER FOUNDATION OVERRIDE

36, ROUND

FOUNDATION TYPE

SQUARE

FOUNDATION SIZE

48.00

CHECK RAILS

FALSE

TOTAL PRICE

9368.94

TOTAL WEIGHT

1712.52

TOTAL PALLETS

2.00
