This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 104.88 inches by 39.76 inches and an array layout of 2 wide by 3 high.
This mount fits on 1 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Crystal 20KVSolar 3×2 thirdGap – V1Jb
$3,745.81
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 104.88 inches by 39.76 inches and an array layout of 2 wide by 3 high.
This mount fits on 1 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
| Weight | 647.84 lbs |
|---|---|
| Dimensions | 90 × 24 × 24 in |
| SKU CODE | 1P-0-6TOP-SD-57-L-3HX2W-C5DC |
| DUTY SIZE | SD |
| POLE SIZE | 6IN, PIPE, SCH, 40 |
| PRODUCT TYPE | BEAM |
| NUMBER OF POLES | 1.00 |
| POLE SPACING | 0.00 |
| POLE HEIGHT | 8.86 |
| WING SPAN | 57.00 |
| MAX FOUNDATION DEPTH | 4.75 |
| TILT ANGLE | 50.00 |
| CANTILEVER | 204.00 |
| GROUND CLEARANCE | 5.00 |
| NO POLES | 1.00 |
| MODULE AREA | 177.61 |
| ARRAY WIDTH | 17.65 |
| ARRAY HEIGHT | 10.06 |
| RAIL LENGTH | 120.78 |
| MODULE LENGTH | 104.88 |
| PASSED OVERHANG CHECK | TRUE |
| MODULE WIDTH GAP | 0.50 |
| MODULE LENGTH GAP | 1.00 |
| TOTAL FRAME LENGTH | 17.00 |
| GROUND TO TOP | 12.71 |
| PROJECTED PANEL HEIGHT | 7.71 |
| WIND SPEED OVERRIDE | NULL |
| SNOW LOAD OVERRIDE | NULL |
| DIRECT SNOW LOAD | FALSE |
| ADD ANGLE BRACE | FALSE |
| DESIGNER NAME | CRYSTAL, 20KV, SOLAR |
| DESIGNER EMAIL | |
| DESIGNER PHONE | 6162621738.00 |
| PROJECT ID | CRYSTAL, 20KVSOLAR, 3X2, THIRDGAP, -, V1JB |
| SITE ADDRESS | COLBY, RD, CRYSTAL, MI, 48818, USA |
| MODULE INFO | 20KV |
| MODULE WIDTH | 39.76 |
| NUMBER ROWS | 3.00 |
| NUMBER COLUMNS | 2.00 |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | B |
| FRAME DUTY OVERRIDE | AUTO |
| POLE OVERRIDE | AUTO |
| SOIL TYPE | SAND |
| CUSTOMER FOUNDATION OVERRIDE | 48, SQUARE |
| FOUNDATION TYPE | SQUARE |
| FOUNDATION SIZE | 48.00 |
| CHECK RAILS | FALSE |
| TOTAL PRICE | 3745.81 |
| TOTAL WEIGHT | 647.84 |
| TOTAL PALLETS | 1.00 |
