This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 65 inches by 39.1 inches and an array layout of 3 wide by 3 high.
This mount fits on 1 – 8in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Meola-Lakewood-v1cu
$4,798.59
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 65 inches by 39.1 inches and an array layout of 3 wide by 3 high.
This mount fits on 1 – 8in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
| Weight | 842.9300000000001 lbs |
|---|---|
| Dimensions | 90 × 24 × 24 in |
| SKU CODE | 1P-0-8TOP-XD-45-L-3HX3W-3B5L |
| DUTY SIZE | XD |
| POLE SIZE | 8IN, PIPE, SCH, 40 |
| PRODUCT TYPE | BEAM |
| NUMBER OF POLES | 1.00 |
| POLE SPACING | 0.00 |
| POLE HEIGHT | 8.18 |
| WING SPAN | 45.00 |
| MAX FOUNDATION DEPTH | 15.00 |
| TILT ANGLE | 40.00 |
| CANTILEVER | 180.00 |
| GROUND CLEARANCE | 5.00 |
| NO POLES | 1.00 |
| MODULE AREA | 163.35 |
| ARRAY WIDTH | 16.50 |
| ARRAY HEIGHT | 9.90 |
| RAIL LENGTH | 118.80 |
| MODULE LENGTH | 65.00 |
| PASSED OVERHANG CHECK | TRUE |
| MODULE WIDTH GAP | 0.50 |
| MODULE LENGTH GAP | 1.00 |
| TOTAL FRAME LENGTH | 15.00 |
| GROUND TO TOP | 11.32 |
| PROJECTED PANEL HEIGHT | 6.28 |
| WIND SPEED OVERRIDE | 175.00 |
| SNOW LOAD OVERRIDE | 150.00 |
| DIRECT SNOW LOAD | FALSE |
| ADD ANGLE BRACE | FALSE |
| PROJECT ID | MEOLA-LAKEWOOD-V1CU |
| SITE ADDRESS | 38, HILLSIDE, RD, IDAHO, SPRINGS, CO, 80452, USA |
| MODULE WIDTH | 39.10 |
| NUMBER ROWS | 3.00 |
| NUMBER COLUMNS | 3.00 |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | C |
| FRAME DUTY OVERRIDE | AUTO |
| POLE OVERRIDE | 8, 40 |
| SOIL TYPE | SAND |
| CUSTOMER FOUNDATION OVERRIDE | 36, ROUND |
| FOUNDATION TYPE | ROUND |
| FOUNDATION SIZE | 36.00 |
| CHECK RAILS | FALSE |
| TOTAL PRICE | 4570.09 |
| TOTAL WEIGHT | 842.93 |
| TOTAL PALLETS | 1.00 |
https://skycivquotes.s3.amazonaws.com/ae356a0b-25ed-4628-8f72-6520f691f234.pdf |
|
| ID | 7494.00 |
| 3D Solar link |
