This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 89.72 inches by 44.65 inches and an array layout of 3 wide by 5 high.
This mount fits on 1 – 10in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Moonstage
$5,584.89
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 89.72 inches by 44.65 inches and an array layout of 3 wide by 5 high.
This mount fits on 1 – 10in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
Weight | 1136.1299999999999 lbs |
---|---|
Dimensions | 90 × 24 × 24 in |
SKU CODE | 1P-0-10TOP-HD-84-L-5HX3W-STRUTS-E7B7 |
DUTY SIZE | HD |
POLE SIZE | 10IN, PIPE, SCH, 40 |
PRODUCT TYPE | BEAM |
NUMBER OF POLES | 1.00 |
POLE SPACING | 0.00 |
POLE HEIGHT | 12.21 |
WING SPAN | 84.00 |
MAX FOUNDATION DEPTH | 7.75 |
TILT ANGLE | 50.00 |
CANTILEVER | 258.00 |
GROUND CLEARANCE | 5.00 |
NO POLES | 1.00 |
MODULE AREA | 426.67 |
ARRAY WIDTH | 22.68 |
ARRAY HEIGHT | 18.81 |
RAIL LENGTH | 225.75 |
MODULE LENGTH | 89.72 |
PASSED OVERHANG CHECK | TRUE |
MODULE WIDTH GAP | 0.50 |
MODULE LENGTH GAP | 1.00 |
TOTAL FRAME LENGTH | 21.50 |
GROUND TO TOP | 19.33 |
PROJECTED PANEL HEIGHT | 14.25 |
PROJECT ID | MOONSTAGE |
SITE ADDRESS | MEADOWS, RD, WHITEFISH, MT, 59937, USA |
MODULE WIDTH | 44.65 |
NUMBER ROWS | 5.00 |
NUMBER COLUMNS | 3.00 |
RISK CATEGORY | I |
EXPOSURE CATEGORY | C |
FRAME DUTY OVERRIDE | AUTO |
POLE OVERRIDE | 10, 40 |
SOIL TYPE | SAND |
CUSTOMER FOUNDATION OVERRIDE | 48, SQUARE |
FOUNDATION TYPE | SQUARE |
FOUNDATION SIZE | 48.00 |
CHECK RAILS | FALSE |
WIND SPEED OVERRIDE | 110.00 |
SNOW LOAD OVERRIDE | 50.00 |
DIRECT SNOW LOAD | FALSE |
ADD ANGLE BRACE | TRUE |
TOTAL PRICE | 5584.89 |
TOTAL WEIGHT | 1136.13 |
TOTAL PALLETS | 1.00 |
https://skycivquotes.s3.amazonaws.com/f71a3b2b-eff0-49dc-b722-c27bb4f8340e.pdf |
|
ID | 6255.00 |
3D Solar link |
