This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 120 inches by 48 inches and an array layout of 1 wide by 3 high.
This mount fits on 1 – 8in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
MTSOLAR_A08ACLIL2JHJ
$3,024.13
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 120 inches by 48 inches and an array layout of 1 wide by 3 high.
This mount fits on 1 – 8in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
| Weight | 497.92 lbs |
|---|---|
| Dimensions | 90 × 24 × 24 in |
| SKU CODE | 1P-0-8TOP-SD-12-L-3HX1W-B1L9 |
| DUTY SIZE | SD |
| POLE SIZE | 8IN, PIPE, SCH, 40 |
| PRODUCT TYPE | BEAM |
| NUMBER OF POLES | 1.00 |
| POLE SPACING | 0.00 |
| POLE HEIGHT | 10.49 |
| WING SPAN | 12.00 |
| MAX FOUNDATION DEPTH | 9.25 |
| TILT ANGLE | 65.00 |
| CANTILEVER | 114.00 |
| GROUND CLEARANCE | 5.00 |
| NO POLES | 1.00 |
| MODULE AREA | 122.26 |
| ARRAY WIDTH | 10.08 |
| ARRAY HEIGHT | 12.13 |
| RAIL LENGTH | 145.50 |
| MODULE LENGTH | 120.00 |
| PASSED OVERHANG CHECK | TRUE |
| MODULE WIDTH GAP | 0.50 |
| MODULE LENGTH GAP | 1.00 |
| TOTAL FRAME LENGTH | 9.50 |
| GROUND TO TOP | 15.93 |
| PROJECTED PANEL HEIGHT | 10.88 |
| PROJECT ID | MTSOLAR, A08ACLIL2JHJ |
| SITE ADDRESS | 637, RAINBOW, TABERNASH, CO, 80478, USA |
| MODULE WIDTH | 48.00 |
| NUMBER ROWS | 3.00 |
| NUMBER COLUMNS | 1.00 |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | C |
| FRAME DUTY OVERRIDE | AUTO |
| POLE OVERRIDE | 8, 40 |
| SOIL TYPE | SAND |
| FOUNDATION TYPE | ROUND |
| FOUNDATION SIZE | 36.00 |
| CHECK RAILS | TRUE |
| WIND SPEED OVERRIDE | 115.00 |
| SNOW LOAD OVERRIDE | 90.00 |
| DIRECT SNOW LOAD | FALSE |
| TOTAL PRICE | 2880.12 |
| TOTAL WEIGHT | 497.92 |
| TOTAL PALLETS | 1.00 |
https://skycivquotes.s3.amazonaws.com/62bd2b31-7c8f-4342-8d2a-080cadca8785.pdf |
|
| ID | 1208.00 |
| 3D Solar link |
