This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 74 inches by 41.5 inches and an array layout of 7 wide by 5 high.
This mount fits on 3 – 6in Pipe Sch 80 inch steel pole(s) with a spacing of 17 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
MTSOLAR_A2I8G79I97AH
$12,352.56
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 74 inches by 41.5 inches and an array layout of 7 wide by 5 high.
This mount fits on 3 – 6in Pipe Sch 80 inch steel pole(s) with a spacing of 17 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
Weight | 2387.08 lbs |
---|---|
Dimensions | 90 × 24 × 24 in |
SKU CODE | 3P-17-6TOP-SD-12-L-5HX7W-25KI |
DUTY SIZE | SD |
POLE SIZE | 6IN, PIPE, SCH, 80 |
PRODUCT TYPE | BEAM |
NUMBER OF POLES | 3.00 |
POLE SPACING | 17.00 |
POLE HEIGHT | 11.70 |
WING SPAN | 12.00 |
MAX FOUNDATION DEPTH | 6.75 |
TILT ANGLE | 50.00 |
CANTILEVER | 522.00 |
GROUND CLEARANCE | 5.00 |
NO POLES | 3.00 |
MODULE AREA | 765.63 |
ARRAY WIDTH | 43.75 |
ARRAY HEIGHT | 17.50 |
RAIL LENGTH | 210.00 |
MODULE LENGTH | 74.00 |
PASSED OVERHANG CHECK | TRUE |
MODULE WIDTH GAP | 0.50 |
MODULE LENGTH GAP | 1.00 |
TOTAL FRAME LENGTH | 43.50 |
GROUND TO TOP | 18.33 |
PROJECTED PANEL HEIGHT | 13.25 |
PROJECT ID | MTSOLAR, A2I8G79I97AH |
SITE ADDRESS | 574, E, RIVER, RD, LINCOLN, VT, 05443, USA |
MODULE WIDTH | 41.50 |
NUMBER ROWS | 5.00 |
NUMBER COLUMNS | 7.00 |
RISK CATEGORY | I |
EXPOSURE CATEGORY | C |
FRAME DUTY OVERRIDE | AUTO |
POLE OVERRIDE | AUTO |
SOIL TYPE | SAND |
CUSTOMER FOUNDATION OVERRIDE | 48, SQUARE |
FOUNDATION TYPE | SQUARE |
FOUNDATION SIZE | 48.00 |
CHECK RAILS | FALSE |
WIND SPEED OVERRIDE | 100.00 |
SNOW LOAD OVERRIDE | 4.00 |
DIRECT SNOW LOAD | FALSE |
ADD ANGLE BRACE | FALSE |
TOTAL PRICE | 12352.56 |
TOTAL WEIGHT | 2387.08 |
TOTAL PALLETS | 3.00 |
https://skycivquotes.s3.amazonaws.com/be9a06c2-67a7-4ea5-8702-98699967bee9.pdf |
|
ID | 7107.00 |
3D Solar link |
