MTSOLAR_BI10G043KBDI – V1Jb

$15,056.63

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 73.385 inches by 40.886 inches and an array layout of 10 wide by 4 high.
This mount fits on 3 – 8in Pipe Sch 80 inch steel pole(s) with a spacing of 22.5 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Add a PE Stamped Drawing for this mount

For permitting, get a Professional Engineer's stamp on your construction drawing.

SKU: 3P-22.5-8TOP-HD-45-L-4Hx10W-0IB2 Category:

Description

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 73.385 inches by 40.886 inches and an array layout of 10 wide by 4 high.
This mount fits on 3 – 8in Pipe Sch 80 inch steel pole(s) with a spacing of 22.5 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Additional information

Weight 2777.85 lbs
Dimensions 90 × 24 × 24 in
SKU CODE

3P-22.5-8TOP-HD-45-L-4HX10W-0IB2

DUTY SIZE

HD

POLE SIZE

8IN, PIPE, SCH, 80

PRODUCT TYPE

BEAM

NUMBER OF POLES

3.00

POLE SPACING

22.50

POLE HEIGHT

15.45

WING SPAN

45.00

MAX FOUNDATION DEPTH

7.75

TILT ANGLE

30.00

CANTILEVER

720.00

GROUND CLEARANCE

12.00

NO POLES

3.00

MODULE AREA

855.14

ARRAY WIDTH

61.99

ARRAY HEIGHT

13.80

RAIL LENGTH

165.54

MODULE LENGTH

73.39

PASSED OVERHANG CHECK

TRUE

MODULE WIDTH GAP

0.50

MODULE LENGTH GAP

1.00

TOTAL FRAME LENGTH

60.00

GROUND TO TOP

18.86

PROJECTED PANEL HEIGHT

6.81

WIND SPEED OVERRIDE

NULL

SNOW LOAD OVERRIDE

NULL

DIRECT SNOW LOAD

FALSE

ADD ANGLE BRACE

FALSE

PROJECT ID

MTSOLAR, BI10G043KBDI, -, V1JB

SITE ADDRESS

VALLEY, FOODS, 204, US-95, LAPWAI, ID, 83540, USA

MODULE WIDTH

40.89

NUMBER ROWS

4.00

NUMBER COLUMNS

10.00

RISK CATEGORY

I

EXPOSURE CATEGORY

C

FRAME DUTY OVERRIDE

AUTO

POLE OVERRIDE

AUTO

SOIL TYPE

SAND

CUSTOMER FOUNDATION OVERRIDE

48, SQUARE

FOUNDATION TYPE

SQUARE

FOUNDATION SIZE

48.00

CHECK RAILS

FALSE

TOTAL PRICE

15056.63

TOTAL WEIGHT

2777.85

TOTAL PALLETS

3.00
