This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 41.1 inches by 87.2 inches and an array layout of 7 wide by 4 high.
This mount fits on 2 – 10in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
MTSOLAR_HB3G2HBLA6EE
$10,295.62
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 41.1 inches by 87.2 inches and an array layout of 7 wide by 4 high.
This mount fits on 2 – 10in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
| Weight | 1723.6399999999999 lbs |
|---|---|
| Dimensions | 90 × 24 × 24 in |
| SKU CODE | 2P-15-10TOP-XD-12-L-4HX7W-0KJG |
| DUTY SIZE | XD |
| POLE SIZE | 10IN, PIPE, SCH, 40 |
| PRODUCT TYPE | BEAM |
| NUMBER OF POLES | 2.00 |
| POLE SPACING | 15.00 |
| POLE HEIGHT | 12.31 |
| WING SPAN | 12.00 |
| MAX FOUNDATION DEPTH | 7.75 |
| TILT ANGLE | 30.00 |
| CANTILEVER | 294.00 |
| GROUND CLEARANCE | 5.00 |
| NO POLES | 2.00 |
| MODULE AREA | 717.92 |
| ARRAY WIDTH | 24.56 |
| ARRAY HEIGHT | 29.23 |
| RAIL LENGTH | 350.80 |
| MODULE LENGTH | 41.10 |
| PASSED OVERHANG CHECK | TRUE |
| MODULE WIDTH GAP | 0.50 |
| MODULE LENGTH GAP | 1.00 |
| TOTAL FRAME LENGTH | 24.50 |
| GROUND TO TOP | 19.57 |
| PROJECTED PANEL HEIGHT | 14.53 |
| WIND SPEED OVERRIDE | NULL |
| SNOW LOAD OVERRIDE | NULL |
| DIRECT SNOW LOAD | FALSE |
| PROJECT ID | MTSOLAR, HB3G2HBLA6EE |
| SITE ADDRESS | 1976, W, ATHENA, CIR, NORTH, POLE, AK, 99705, USA |
| MODULE WIDTH | 87.20 |
| NUMBER ROWS | 4.00 |
| NUMBER COLUMNS | 7.00 |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | C |
| FRAME DUTY OVERRIDE | AUTO |
| POLE OVERRIDE | AUTO |
| SOIL TYPE | SAND |
| CUSTOMER FOUNDATION OVERRIDE | 48, SQUARE |
| FOUNDATION TYPE | SQUARE |
| FOUNDATION SIZE | 48.00 |
| CHECK RAILS | FALSE |
| TOTAL PRICE | 9805.35 |
| TOTAL WEIGHT | 1723.64 |
| TOTAL PALLETS | 2.00 |
https://skycivquotes.s3.amazonaws.com/d4b75531-7957-421f-bf6b-b041754ea1fc.pdf |
|
| ID | 2544.00 |
| 3D Solar link |
