This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 44.7 inches by 95.1 inches and an array layout of 6 wide by 3 high.
This mount fits on 1 – 8in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
MTSOLAR_ILFBJD7EK38F – V1Jb
$6,178.16
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 44.7 inches by 95.1 inches and an array layout of 6 wide by 3 high.
This mount fits on 1 – 8in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
| Weight | 1121.97 lbs |
|---|---|
| Dimensions | 90 × 24 × 24 in |
| SKU CODE | 1P-0-8TOP-XD-84-L-3HX6W-STRUTS-I8JI |
| DUTY SIZE | XD |
| POLE SIZE | 8IN, PIPE, SCH, 40 |
| PRODUCT TYPE | BEAM |
| NUMBER OF POLES | 1.00 |
| POLE SPACING | 0.00 |
| POLE HEIGHT | 14.05 |
| WING SPAN | 84.00 |
| MAX FOUNDATION DEPTH | 7.00 |
| TILT ANGLE | 25.00 |
| CANTILEVER | 258.00 |
| GROUND CLEARANCE | 9.00 |
| NO POLES | 1.00 |
| MODULE AREA | 546.12 |
| ARRAY WIDTH | 22.85 |
| ARRAY HEIGHT | 23.90 |
| RAIL LENGTH | 286.80 |
| MODULE LENGTH | 44.70 |
| PASSED OVERHANG CHECK | TRUE |
| MODULE WIDTH GAP | 0.50 |
| MODULE LENGTH GAP | 1.00 |
| TOTAL FRAME LENGTH | 21.50 |
| GROUND TO TOP | 19.10 |
| PROJECTED PANEL HEIGHT | 10.10 |
| WIND SPEED OVERRIDE | 100.00 |
| SNOW LOAD OVERRIDE | 30.00 |
| DIRECT SNOW LOAD | FALSE |
| ADD ANGLE BRACE | TRUE |
| DESIGNER NAME | EVE, HOSKINS |
| DESIGNER EMAIL | |
| DESIGNER PHONE | 9282433881.00 |
| PROJECT ID | MTSOLAR, ILFBJD7EK38F, -, V1JB |
| SITE ADDRESS | SHOW, LOW, AZ, 85901, USA |
| MODULE WIDTH | 95.10 |
| NUMBER ROWS | 3.00 |
| NUMBER COLUMNS | 6.00 |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | B |
| FRAME DUTY OVERRIDE | AUTO |
| POLE OVERRIDE | AUTO |
| SOIL TYPE | SAND |
| CUSTOMER FOUNDATION OVERRIDE | 48, SQUARE |
| FOUNDATION TYPE | SQUARE |
| FOUNDATION SIZE | 48.00 |
| CHECK RAILS | FALSE |
| TOTAL PRICE | 6178.16 |
| TOTAL WEIGHT | 1121.97 |
| TOTAL PALLETS | 1.00 |
