This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 71.01 inches by 44.65 inches and an array layout of 4 wide by 5 high.
This mount fits on 2 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
MTSOLAR_Lithuania_apkrovos 2 pole_new
$8,362.79
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 71.01 inches by 44.65 inches and an array layout of 4 wide by 5 high.
This mount fits on 2 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
| Weight | 1632.9 lbs |
|---|---|
| Dimensions | 90 × 24 × 24 in |
| SKU CODE | 2P-15-6TOP-HD-12-L-5HX4W-927G |
| DUTY SIZE | HD |
| POLE SIZE | 6IN, PIPE, SCH, 40 |
| PRODUCT TYPE | BEAM |
| NUMBER OF POLES | 2.00 |
| POLE SPACING | 15.00 |
| POLE HEIGHT | 11.50 |
| WING SPAN | 12.00 |
| MAX FOUNDATION DEPTH | 3.75 |
| TILT ANGLE | 30.00 |
| CANTILEVER | 294.00 |
| GROUND CLEARANCE | 6.80 |
| NO POLES | 2.00 |
| MODULE AREA | 451.56 |
| ARRAY WIDTH | 24.00 |
| ARRAY HEIGHT | 18.81 |
| RAIL LENGTH | 225.75 |
| MODULE LENGTH | 71.01 |
| PASSED OVERHANG CHECK | TRUE |
| MODULE WIDTH GAP | 0.50 |
| MODULE LENGTH GAP | 1.00 |
| TOTAL FRAME LENGTH | 24.50 |
| GROUND TO TOP | 16.15 |
| PROJECTED PANEL HEIGHT | 9.30 |
| WIND SPEED OVERRIDE | 54.00 |
| SNOW LOAD OVERRIDE | 33.42 |
| DIRECT SNOW LOAD | TRUE |
| ADD ANGLE BRACE | TRUE |
| PROJECT ID | MTSOLAR, LITHUANIA, APKROVOS, 2, POLE, NEW |
| SITE ADDRESS | J64H+HH, BURDETTE, SD, 57373, USA |
| MODULE WIDTH | 44.65 |
| NUMBER ROWS | 5.00 |
| NUMBER COLUMNS | 4.00 |
| RISK CATEGORY | I |
| EXPOSURE CATEGORY | B |
| FRAME DUTY OVERRIDE | AUTO |
| POLE OVERRIDE | AUTO |
| SOIL TYPE | SAND |
| CUSTOMER FOUNDATION OVERRIDE | 48, SQUARE |
| FOUNDATION TYPE | SQUARE |
| FOUNDATION SIZE | 48.00 |
| CHECK RAILS | FALSE |
| TOTAL PRICE | 8362.79 |
| TOTAL WEIGHT | 1632.90 |
| TOTAL PALLETS | 2.00 |
https://skycivquotes.s3.amazonaws.com/97057a73-1c9d-4382-a34f-ad04b49b7190.pdf |
|
| ID | 4874.00 |
| 3D Solar link |
