Silver Lake Well – 2P – 2×4 – V2Jb

$8,573.29

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 72 inches by 44.65 inches and an array layout of 4 wide by 4 high.
This mount fits on 2 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Add a PE Stamped Drawing for this mount

For permitting, get a Professional Engineer's stamp on your construction drawing.

SKU: 2P-15-6TOP-XD-12-L-4Hx4W-9579 Category:

Description

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 72 inches by 44.65 inches and an array layout of 4 wide by 4 high.
This mount fits on 2 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Additional information

Weight 1551.98 lbs
Dimensions 90 × 24 × 24 in
SKU CODE

2P-15-6TOP-XD-12-L-4HX4W-9579

DUTY SIZE

XD

POLE SIZE

6IN, PIPE, SCH, 40

PRODUCT TYPE

BEAM

NUMBER OF POLES

2.00

POLE SPACING

15.00

POLE HEIGHT

8.16

WING SPAN

12.00

MAX FOUNDATION DEPTH

5.50

TILT ANGLE

55.00

CANTILEVER

294.00

GROUND CLEARANCE

2.00

NO POLES

2.00

MODULE AREA

366.22

ARRAY WIDTH

24.33

ARRAY HEIGHT

15.05

RAIL LENGTH

180.60

MODULE LENGTH

72.00

PASSED OVERHANG CHECK

TRUE

MODULE WIDTH GAP

0.50

MODULE LENGTH GAP

1.00

TOTAL FRAME LENGTH

24.50

GROUND TO TOP

14.26

PROJECTED PANEL HEIGHT

12.19

WIND SPEED OVERRIDE

89.00

SNOW LOAD OVERRIDE

597.00

DIRECT SNOW LOAD

FALSE

ADD ANGLE BRACE

FALSE

PROJECT ID

SILVER, LAKE, WELL, -, 2P, -, 2X4, -, V2JB

SITE ADDRESS

KIT, CARSON, CA, 95666, USA

MODULE WIDTH

44.65

NUMBER ROWS

4.00

NUMBER COLUMNS

4.00

RISK CATEGORY

I

EXPOSURE CATEGORY

B

FRAME DUTY OVERRIDE

AUTO

POLE OVERRIDE

AUTO

SOIL TYPE

SAND

CUSTOMER FOUNDATION OVERRIDE

36, ROUND

FOUNDATION TYPE

ROUND

FOUNDATION SIZE

36.00

CHECK RAILS

FALSE

TOTAL PRICE

8573.29

TOTAL WEIGHT

1551.98

TOTAL PALLETS

2.00
