Wolfe road Aptos 400W

$4,721.22

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 67.7 inches by 44.6 inches and an array layout of 4 wide by 4 high.
This mount fits on 1 – 8in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Add a PE Stamped Drawing for this mount

For permitting, get a Professional Engineer's stamp on your construction drawing.

SKU: 1P-0-8TOP-SD-84-L-4Hx4W-STRUTS-271A Category:

Description

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 67.7 inches by 44.6 inches and an array layout of 4 wide by 4 high.
This mount fits on 1 – 8in Pipe Sch 40 inch steel pole(s) with a spacing of 0 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Additional information

Weight 836.38 lbs
Dimensions 90 × 24 × 24 in
SKU CODE

1P-0-8TOP-SD-84-L-4HX4W-STRUTS-271A

DUTY SIZE

SD

POLE SIZE

8IN, PIPE, SCH, 40

PRODUCT TYPE

BEAM

NUMBER OF POLES

1.00

POLE SPACING

0.00

POLE HEIGHT

6.96

WING SPAN

84.00

MAX FOUNDATION DEPTH

5.50

TILT ANGLE

50.00

CANTILEVER

258.00

GROUND CLEARANCE

1.20

NO POLES

1.00

MODULE AREA

344.26

ARRAY WIDTH

22.90

ARRAY HEIGHT

15.03

RAIL LENGTH

180.40

MODULE LENGTH

67.70

PASSED OVERHANG CHECK

TRUE

MODULE WIDTH GAP

0.50

MODULE LENGTH GAP

1.00

TOTAL FRAME LENGTH

21.50

GROUND TO TOP

12.65

PROJECTED PANEL HEIGHT

11.39

PROJECT ID

WOLFE, ROAD, APTOS, 400W

SITE ADDRESS

1339, WOLFE, RD, GUFFEY, CO, 80820, USA

MODULE WIDTH

44.60

NUMBER ROWS

4.00

NUMBER COLUMNS

4.00

RISK CATEGORY

I

EXPOSURE CATEGORY

C

FRAME DUTY OVERRIDE

AUTO

POLE OVERRIDE

8, 40

SOIL TYPE

SAND

CUSTOMER FOUNDATION OVERRIDE

48, SQUARE

FOUNDATION TYPE

SQUARE

FOUNDATION SIZE

48.00

CHECK RAILS

FALSE

WIND SPEED OVERRIDE

110.00

SNOW LOAD OVERRIDE

52.00

DIRECT SNOW LOAD

FALSE

ADD ANGLE BRACE

TRUE

TOTAL PRICE

4721.22

TOTAL WEIGHT

836.38

TOTAL PALLETS

1.00
