This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 69.37 inches by 44.65 inches and an array layout of 6 wide by 4 high.
This mount fits on 2 – 8in Pipe Sch 80 inch steel pole(s) with a spacing of 19.75 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

SKU: 2P-19.75-8TOP-SD-45-L-4Hx6W-1LDF Category:

Description

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 69.37 inches by 44.65 inches and an array layout of 6 wide by 4 high.
This mount fits on 2 – 8in Pipe Sch 80 inch steel pole(s) with a spacing of 19.75 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Additional information

Weight 1466.82 lbs
Dimensions 90 × 24 × 24 in
SKU CODE

2P-19.75-8TOP-SD-45-L-4HX6W-1LDF

DUTY SIZE

SD

POLE SIZE

8IN, PIPE, SCH, 80

PRODUCT TYPE

BEAM

NUMBER OF POLES

2.00

POLE SPACING

19.75

POLE HEIGHT

11.50

WING SPAN

45.00

MAX FOUNDATION DEPTH

8.00

TILT ANGLE

85.00

CANTILEVER

417.00

GROUND CLEARANCE

4.00

NO POLES

2.00

MODULE AREA

529.53

ARRAY WIDTH

35.19

ARRAY HEIGHT

15.05

RAIL LENGTH

180.60

MODULE LENGTH

69.37

PASSED OVERHANG CHECK

TRUE

MODULE WIDTH GAP

0.50

MODULE LENGTH GAP

1.00

TOTAL FRAME LENGTH

34.75

GROUND TO TOP

18.91

PROJECTED PANEL HEIGHT

14.83

PROJECT ID

MTSOLAR, B72G5LA79GCA

SITE ADDRESS

16915, E, LAUREL, RD, ELK, WA, 99009, USA

MODULE WIDTH

44.65

NUMBER ROWS

4.00

NUMBER COLUMNS

6.00

RISK CATEGORY

I

EXPOSURE CATEGORY

C

FRAME DUTY OVERRIDE

AUTO

POLE OVERRIDE

AUTO

SOIL TYPE

SAND

CUSTOMER FOUNDATION OVERRIDE

48, SQUARE

FOUNDATION TYPE

SQUARE

FOUNDATION SIZE

48.00

CHECK RAILS

FALSE

WIND SPEED OVERRIDE

110.00

SNOW LOAD OVERRIDE

70.00

DIRECT SNOW LOAD

FALSE

ADD ANGLE BRACE

FALSE

TOTAL PRICE

8312.45

TOTAL WEIGHT

1466.82

TOTAL PALLETS

2.00
