This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 96 inches by 52 inches and an array layout of 7 wide by 5 high.
This mount fits on 3 – 8in Pipe Sch 40 inch steel pole(s) with a spacing of 19.75 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Add a PE Stamped Drawing for this mount

For permitting, get a Professional Engineer's stamp on your construction drawing.

Product price: $15,123.93
Total options:
Order total:
SKU: 3P-19.75-8TOP-HD-57-L-5Hx7W-ECDD Category:

Description

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 96 inches by 52 inches and an array layout of 7 wide by 5 high.
This mount fits on 3 – 8in Pipe Sch 40 inch steel pole(s) with a spacing of 19.75 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Additional information

Weight 3045.77 lbs
Dimensions 90 × 24 × 24 in
SKU CODE

3P-19.75-8TOP-HD-57-L-5HX7W-ECDD

DUTY SIZE

HD

POLE SIZE

8IN, PIPE, SCH, 40

PRODUCT TYPE

BEAM

NUMBER OF POLES

3.00

POLE SPACING

19.75

POLE HEIGHT

10.80

WING SPAN

57.00

MAX FOUNDATION DEPTH

6.75

TILT ANGLE

32.00

CANTILEVER

678.00

GROUND CLEARANCE

5.00

NO POLES

3.00

MODULE AREA

1237.76

ARRAY WIDTH

56.58

ARRAY HEIGHT

21.88

RAIL LENGTH

262.50

MODULE LENGTH

96.00

PASSED OVERHANG CHECK

TRUE

MODULE WIDTH GAP

0.50

MODULE LENGTH GAP

1.00

TOTAL FRAME LENGTH

56.50

GROUND TO TOP

16.54

PROJECTED PANEL HEIGHT

11.48

WIND SPEED OVERRIDE

NULL

SNOW LOAD OVERRIDE

NULL

DIRECT SNOW LOAD

FALSE

ADD ANGLE BRACE

FALSE

PROJECT ID

TESTING, -, V1JB

SITE ADDRESS

41902, N, CIRCLE, DR, ANTIOCH, IL, 60002, USA

MODULE WIDTH

52.00

NUMBER ROWS

5.00

NUMBER COLUMNS

7.00

RISK CATEGORY

I

EXPOSURE CATEGORY

B

FRAME DUTY OVERRIDE

AUTO

POLE OVERRIDE

AUTO

SOIL TYPE

SAND

CUSTOMER FOUNDATION OVERRIDE

48, SQUARE

FOUNDATION TYPE

SQUARE

FOUNDATION SIZE

48.00

CHECK RAILS

FALSE

TOTAL PRICE

15123.93

TOTAL WEIGHT

3045.77

TOTAL PALLETS

3.00
