This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 97.6 inches by 39 inches and an array layout of 3 wide by 3 high.
This mount fits on 2 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
FFARAGRIVOLTICSSTUDY-JB-30inmodgaps-RevB
$6,017.76
Description
This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 97.6 inches by 39 inches and an array layout of 3 wide by 3 high.
This mount fits on 2 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 15 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here
Additional information
Weight | 1067.88 lbs |
---|---|
Dimensions | 90 × 24 × 24 in |
SKU CODE | 2P-15-6TOP-SD-12-L-3HX3W-L980 |
DUTY SIZE | SD |
POLE SIZE | 6IN, PIPE, SCH, 40 |
PRODUCT TYPE | BEAM |
NUMBER OF POLES | 2.00 |
POLE SPACING | 15.00 |
POLE HEIGHT | 8.43 |
WING SPAN | 12.00 |
MAX FOUNDATION DEPTH | 3.25 |
TILT ANGLE | 5.00 |
CANTILEVER | 294.00 |
GROUND CLEARANCE | 8.00 |
NO POLES | 2.00 |
MODULE AREA | 243.42 |
ARRAY WIDTH | 24.65 |
ARRAY HEIGHT | 9.88 |
RAIL LENGTH | 118.50 |
MODULE LENGTH | 97.60 |
PASSED OVERHANG CHECK | TRUE |
MODULE WIDTH GAP | 0.50 |
MODULE LENGTH GAP | 1.00 |
TOTAL FRAME LENGTH | 24.50 |
GROUND TO TOP | 8.86 |
PROJECTED PANEL HEIGHT | 0.85 |
WIND SPEED OVERRIDE | NULL |
SNOW LOAD OVERRIDE | NULL |
DIRECT SNOW LOAD | FALSE |
ADD ANGLE BRACE | FALSE |
PROJECT ID | FFARAGRIVOLTICSSTUDY-JB-30INMODGAPS-REVB |
SITE ADDRESS | 2100, ATLANTA, AVE, RIVERSIDE, CA, 92507, USA |
MODULE WIDTH | 39.00 |
NUMBER ROWS | 3.00 |
NUMBER COLUMNS | 3.00 |
RISK CATEGORY | I |
EXPOSURE CATEGORY | C |
FRAME DUTY OVERRIDE | AUTO |
POLE OVERRIDE | AUTO |
SOIL TYPE | SAND |
CUSTOMER FOUNDATION OVERRIDE | 48, SQUARE |
FOUNDATION TYPE | SQUARE |
FOUNDATION SIZE | 48.00 |
CHECK RAILS | FALSE |
TOTAL PRICE | 6017.76 |
TOTAL WEIGHT | 1067.88 |
TOTAL PALLETS | 2.00 |
