This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 69.13 inches by 40.9 inches and an array layout of 10 wide by 5 high.
This mount fits on 3 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 19.75 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Add a PE Stamped Drawing for this mount

For permitting, get a Professional Engineer's stamp on your construction drawing.

SKU: 3P-19.75-6TOP-HD-57-L-5Hx10W-STRUTS-7I76 Category:

Description

This Pole Mount is designed to meet your site-specific inputs which are modules with dimensions of 69.13 inches by 40.9 inches and an array layout of 10 wide by 5 high.
This mount fits on 3 – 6in Pipe Sch 40 inch steel pole(s) with a spacing of 19.75 feet (not included).
The package includes a rail kit with all hardware necessary to attach and bond the solar modules to the rack. A chain hoist and lift bracket are needed for each pole (not included).
See 3D Model Here

Additional information

Weight 3305.09 lbs
Dimensions 90 × 24 × 24 in
SKU CODE

3P-19.75-6TOP-HD-57-L-5HX10W-STRUTS-7I76

DUTY SIZE

HD

POLE SIZE

6IN, PIPE, SCH, 40

PRODUCT TYPE

BEAM

NUMBER OF POLES

3.00

POLE SPACING

19.75

POLE HEIGHT

12.70

WING SPAN

57.00

MAX FOUNDATION DEPTH

4.75

TILT ANGLE

8.00

CANTILEVER

678.00

GROUND CLEARANCE

11.50

NO POLES

3.00

MODULE AREA

1008.12

ARRAY WIDTH

58.44

ARRAY HEIGHT

17.25

RAIL LENGTH

207.00

MODULE LENGTH

69.13

PASSED OVERHANG CHECK

TRUE

MODULE WIDTH GAP

0.50

MODULE LENGTH GAP

1.00

TOTAL FRAME LENGTH

56.50

GROUND TO TOP

13.89

PROJECTED PANEL HEIGHT

2.37

WIND SPEED OVERRIDE

106.00

SNOW LOAD OVERRIDE

30.00

DIRECT SNOW LOAD

FALSE

ADD ANGLE BRACE

TRUE

PROJECT ID

SOLAR, MONTANA

SITE ADDRESS

2845, N, SANDERS, ST, HELENA, MT, 59601, USA

MODULE WIDTH

40.90

NUMBER ROWS

5.00

NUMBER COLUMNS

10.00

RISK CATEGORY

I

EXPOSURE CATEGORY

C

FRAME DUTY OVERRIDE

HD

POLE OVERRIDE

AUTO

SOIL TYPE

SANDY, GRAVEL

CUSTOMER FOUNDATION OVERRIDE

48, SQUARE

FOUNDATION TYPE

SQUARE

FOUNDATION SIZE

48.00

CHECK RAILS

TRUE

TOTAL PRICE

16382.91

TOTAL WEIGHT

3305.09

TOTAL PALLETS

3.00
